• Rated Power: 249.9 W
• Output Voltage Range: 119 – 238 V DC (Constant Current Region)
• Rated Current: 1050 mA (Adjustable 525 – 1050 mA via potentiometer)
• Input Voltage Range: 90 – 305 V AC / 127 – 431 V DC, 47 – 63 Hz
• Efficiency: Up to 94 %
• Current Ripple: 5.0% max. @ rated current
• Inrush Current: Cold start 75 A (t_width = 700 µs at 230 V AC)
• No-load Power Consumption: < 0.5 W
• Operating Temperature: −40 °C to +90 °C (Tcase)
• Cooling: Free air convection
• Protections: Short circuit, Over voltage, Over temperature
• Surge Immunity: 4KV Line-Earth, 2KV Line-Line
• Isolation Voltage: 3.75 KV AC (Input to Output)
• Dimensions (L x W x H): 244.2 mm x 68 mm x 38.8 mm
• Weight: Approx. 1300 g
• Safety & EMC Standards: UL8750, EN61347-1, EN61347-2-13, IP65, EAC
• Adjustment Type: Internal Potentiometer for Output Current
• Manufacturer Warranty: 7 Years

Information about the MEAN WELL HLG-240H-C1050A

The MEAN WELL HLG-240H-C1050A is a high-performance 250W AC/DC LED driver designed for high-voltage, constant current architectural and industrial lighting systems. This A-Type model is characterized by its IP65-rated aluminum housing, which ensures reliable protection against dust and moisture ingress, making it a perfect fit for rugged indoor and outdoor installations. A key technical advantage is the built-in potentiometer, which enables installers to manually fine-tune the output current from 525 mA to 1050 mA, providing the flexibility needed to match specific LED string requirements. Delivering a peak efficiency of 94 %, the unit minimizes thermal loss, supporting fanless operation through free air convection even in extreme environmental conditions up to a +90 °C case temperature. Its advanced design includes active Power Factor Correction (PFC) and complies with "Type HL" standards for use in hazardous (Classified) locations. With a proven lifetime of over 62,000 hours and an industry-standard 7-year manufacturer warranty, the HLG-240H-C1050A offers a highly dependable and cost-effective solution for LED street lighting, high-bay fixtures, and large-scale architectural illumination.
