• Output Power: 200 W
• Output Voltage Range: 200 – 400 V DC
• Output Current: 500 mA
• Input Voltage Range: 90 – 305 V AC / 127 – 431 V DC, 47 – 63 Hz
• Efficiency: up to 94 %
• Current Ripple: max. 5.0%
• Inrush Current: 55 A @ 230 V AC (Cold start)
• Power Factor: PF ≥ 0.98 @ 115 VAC / PF ≥ 0.95 @ 230 VAC
• Operating Temperature: −40 °C to +90 °C (T-case)
• Cooling: Fanless natural convection
• Protection Functions: Short circuit, Over voltage, Over temperature
• Ingress Protection: IP65 / IP67 (depending on model)
• Isolation Voltage: 3750 V AC between Input and Output
• Dimensions (L x W x H): 228 mm x 68 mm x 38.8 mm
• Weight: 1.15 kg
• Safety & EMC Certificates: UL8750, EN61347-1, EN61347-2-13, CE, EAC
• MTBF: > 192,000 hours
• Manufacturer Warranty: 7 years

Detailed Information on the MEAN WELL HLG-185H-C500

The MEAN WELL HLG-185H-C500 is a high-performance 200W LED driver engineered for constant current mode output at high voltage levels. Featuring an industry-leading efficiency of up to 94%, this power supply minimizes energy loss and heat generation within its durable metal housing. Designed for maximum reliability, the fanless architecture allows the device to operate seamlessly via free air convection across a wide temperature spectrum from -40 °C to +90 °C. Furthermore, the built-in active PFC function ensures compliance with global harmonic current regulations, providing a stable and clean power supply for high-end LED systems.

This driver is highly adaptable to harsh environments, boasting IP65 and IP67 ingress protection, making it suitable for both indoor and outdoor installations such as LED street lighting, high bay lighting, and architectural floodlights. A key highlight of the HLG-185H-C series is its exceptional longevity, with a typical lifetime exceeding 62,000 hours, ensuring long-term operational stability. To provide maximum security for your investment, MEAN WELL offers a comprehensive 7-year manufacturer warranty. This combination of high voltage capability, robust environmental protection, and long-term durability makes it the preferred choice for mission-critical lighting projects.
