Technical Information & Details for the MEAN WELL HLG-120H-C1400A
- Rated Power: 151.2 W
- Rated Current: 1400 mA
- Constant Current Region: 54 – 108 V DC
- Input Voltage Range: 90 – 305 V AC / 127 – 431 V DC
- Efficiency (typ.): 92 %
- Current Adj. Range: 700 – 1400 mA (via internal potentiometer)
- Operating Temp. (Case): −40 °C to +90 °C
- IP Rating: IP65
- Typical Lifetime: > 62,000 hours
- Manufacturer Warranty: 7 Years
Information about the MEAN WELL HLG-120H-C1400A
The MEAN WELL HLG-120H-C1400A is a high-performance 150W AC/DC LED driver featuring constant current mode output. As an "A-Type" model, it is housed in a rugged IP65-rated metal enclosure and includes a built-in potentiometer, allowing installers to manually adjust the output current from 700mA to 1400mA to meet specific application requirements.
With an efficiency of 92% and a fanless design, the unit operates reliably under natural air convection even in extreme temperatures. It is specifically designed for LED street lighting, bay lighting, and greenhouse lighting. The driver includes active Power Factor Correction (PFC) and full protection against short circuit, overvoltage, and overtemperature, ensuring a long operational life of over 62,000 hours.
