• Output Power: 70 W
• Output Current: 350 mA
• Current Tolerance: ±5 %
• Current Ripple: ≤ 5.0 % max. rated current
• Constant Current Region: 100 – 200 V
• Input Voltage Range: 90 – 305 V AC / 127 – 431 V DC, 47 – 63 Hz
• Efficiency: up to 91 %
• Inrush Current: 60 A (Peak @230 VAC, width 275 µs)
• No-Load Power Consumption: < 0.75 W
• Hold-up Time: 750 ms @115 VAC / 500 ms @230 VAC
• Operating Temperature: −40 °C to +80 °C
• Max. Case Temperature: Tcase 80 °C
• Cooling: fanless free air convection
• Protections: Short circuit (Hiccup mode, auto-recovery), Overload, Over voltage, Over temperature
• Surge Immunity: Line-Earth 4 kV, Line-Line 2 kV (IEC61000-4-5)
• Isolation Voltage: 3.75 kV AC IP-OP / 2 kV AC IP-FG / 1.5 kV AC OP-FG
• Dimensions (L x W x H): 171 mm x 61.5 mm x 36.8 mm
• Weight: ca. 730 g
• Safety & EMC Certifications: UL8750, CSA C22.2, EN61347-1/-2-13, GB19510.1/.14, EAC TP TC 004
• IP Rating: IP65 / IP67 (model dependent)
• Manufacturer Warranty: 7 years

Information on MEAN WELL HLG-60H-C350A

The MEAN WELL HLG-60H-C350A is a premium 70 W Constant Current (CC mode) LED driver designed for demanding LED applications, featuring rugged IP65/IP67 rating for indoor and outdoor use. It delivers precise 350 mA current with high efficiency up to 91 % and active PFC (>0.95), ensuring energy-efficient and stable operation for long LED strings up to 200 V. The wide 90–305 V AC input range and heavy industrial surge immunity make it perfect for global harsh environments.

Key Strengths: Wide temperature range −40 °C to +80 °C with Tcase up to 80 °C and lifespan >62,000 hours at Tcase=75 °C, automatic hiccup protection recovery for maximum uptime, THD <20 % for clean power quality, and MTBF >3,113,000 hours. Ideal for LED streetlights, tunnel lighting, high-bay fixtures, and industrial area lighting – with fanless convection and full metal housing for superior reliability and longevity.
