Technical Specifications & Details for MEAN WELL ELG-75-12A-3Y Power Supply
- Output Power: 60 W
- Output Voltage: 12 V DC (adjustable 10.8–13.2 V)
- Output Current: 2.5–5 A (adjustable)
- Input Voltage Range: 100–305 V AC / 142–431 V DC, 47–63 Hz
- Efficiency: up to 86 %
- Ripple & Noise: ≤ 150 mVp-p
- Inrush Current: max. 50 A
- No-Load Power Consumption: < 0.5 W
- Operating Temperature: −40 °C to +85 °C (Case)
- Cooling: free air convection
- Protections: Short circuit (Hiccup), Overload, Overvoltage, Over temperature
- Overvoltage Category: OVC II
- Isolation Voltage: 3.75 kV AC IP-OP
- Dimensions (L x W x H): 169 mm x 63 mm x 35.5 mm
- Weight: ca. 800 g
- Safety & EMC Certificates: UL8750, IEC/EN 61347-1/-2-13, IP65, CE, Active PFC
- Manufacturer Warranty: 5 Years
Information on MEAN WELL ELG-75-12A-3Y
The MEAN WELL ELG-75-12A-3Y is a highly flexible 60-W LED driver power supply featuring unique adjustability of both output voltage (10.8–13.2 V) and current (2.5–5 A) via built-in potentiometers, specifically engineered for professional lighting applications with variable requirements. It excels with integrated Active PFC for optimal power factor correction, IP65 protection against dust and water jets, and an extremely wide input voltage range of 100–305 V AC enabling worldwide deployment without adapters. The rugged aluminum construction operates reliably across -40 °C to +85 °C case temperatures while delivering efficiency up to 86 % and low ripple ≤150 mVp-p for flicker-free perfect LED performance in strips, panels, and industrial lighting.
Featuring complete protection functions with Hiccup mode and automatic recovery plus international certifications including UL8750 and IEC/EN 61347 standards, the ELG-75-12A-3Y ensures maximum operational safety even in the most demanding commercial and industrial environments. Its compact 169 x 63 x 35.5 mm aluminum housing with MTBF exceeding 345,000 hours and minimal no-load consumption <0.5 W makes it the ideal solution for durable, low-maintenance LED systems, completed by an extended 5-year manufacturer warranty for ultimate investment protection.
