• Output Power: 75.6 W
• Output Voltage: 36 V DC (adjustable 32.4 – 39.6 V DC)
• Output Current: 2.1 A (adjustable 1.05 – 2.1 A)
• Input Voltage Range: 100 – 305 V AC / 142 – 431 V DC, 47 – 63 Hz
• Efficiency: up to 89%
• Ripple & Noise: ≤ 250 mVp-p
• Inrush Current: max. 50 A @ 230 VAC
• No-Load Power Consumption: < 0.5 W
• Operating Temperature: −40 °C to +85 °C
• Cooling: fanless natural convection
• Protections: Short circuit, overcurrent, overvoltage, overtemperature
• IP Rating: IP65
• Isolation Voltage: 3750 V AC between input and output
• Dimensions (L x W x H): 180 mm x 63 mm x 35.5 mm
• Weight: approx. 800 g
• Safety & EMC Certificates: CE, ENEC, TUV, CB, EAC, UKCA
• Power Factor Correction (PFC): Active
• Manufacturer Warranty: 5 Years

Information about the MEAN WELL ELG-75-36A

The MEAN WELL ELG-75-36A is a high-performance and exceptionally reliable LED power supply that stands out for its incredible flexibility in demanding indoor and outdoor lighting applications. The defining feature of this specific "A" variant is the inclusion of built-in potentiometers, allowing users to precisely tune both the output voltage (ranging from 32.4 to 39.6 V DC) and the constant current (from 1.05 to 2.1 A) to perfectly match the exact electrical requirements of any custom LED project. Housed within a rugged metal enclosure that holds a strict IP65 rating, the device provides outstanding protection against dust and water ingress. Driven by integrated active Power Factor Correction (PFC) technology, this advanced LED driver delivers an impressive energy efficiency of up to 89% while significantly reducing the load on the electrical grid, operating safely and consistently in a dual constant voltage and constant current mode.

Engineered for maximum global compatibility, this power supply features an ultra-wide input voltage range of 100 to 305 V AC, making it highly resilient against power fluctuations often found in harsh industrial environments. Its fanless design relies entirely on natural convection for cooling, ensuring silent and dependable operation across an extreme operating temperature range of −40 °C to +85 °C without any risk of mechanical fan failure. To guarantee absolute safety and longevity during continuous operation, the unit is fully equipped with comprehensive protection mechanisms that instantly safeguard against short circuits, overcurrent, overvoltage, and overtemperature events. Backed by a generous 5-year manufacturer warranty, the MEAN WELL ELG-75-36A proves to be an ideal, highly durable power solution for professional deployments including architectural lighting, commercial floodlights, and robust street lamps.
