Technical Information & Details for the MEAN WELL HLG-120H-C700A
- Rated Power: 154 W
- Rated Current: 700 mA
- Constant Current Region: 110 – 220 V DC
- Input Voltage Range: 90 – 305 V AC / 127 – 431 V DC
- Efficiency (typ.): 94 %
- Current Adj. Range: 350 – 700 mA (via internal potentiometer)
- Operating Temp. (Case): −40 °C to +90 °C
- IP Rating: IP65
- Typical Lifetime: > 62,000 hours
- Manufacturer Warranty: 7 Years
Information about the MEAN WELL HLG-120H-C700A
The MEAN WELL HLG-120H-C700A is a high-performance 150W AC/DC LED driver featuring constant current mode and high voltage output. As an "A-Type" model, it is housed in a rugged IP65-rated metal enclosure. It features a built-in potentiometer that allows installers to manually adjust the output current level from 350mA to 700mA, ensuring the perfect power match for specific LED arrays.
With an efficiency of up to 94% and a fanless design, the unit operates reliably under natural air convection even in extreme temperature environments. It is specifically designed for demanding applications such as high-mast lighting, greenhouse systems, and industrial bay lighting. The driver includes active Power Factor Correction (PFC) and full protection against short circuit, overvoltage, and overtemperature.
