Technical Information & Details for MEAN WELL ELG-200-42DA Power Supply
- Output Power: 201.6 W (at 200–305 VAC) / 149.94 W (at 100–180 VAC)
- Output Voltage: 42 V DC
- Output Current: 4.8 A
- Input Voltage Range: 100 – 305 V AC / 142 – 431 V DC, 47 – 63 Hz
- Efficiency: 92.5%
- Ripple & Noise: ≤ 250 mVp-p
- Inrush Current: 60 A at 230 VAC (Cold Start)
- Standby Power Consumption: < 0.5 W
- Operating Temperature: −40 °C to +90 °C (Case Temperature Tcase)
- Cooling: Fanless Free Air Convection
- Protections: Over Current, Short Circuit, Over Voltage, Over Temperature
- Overvoltage Category: OVC III (Design Compliance)
- Isolation Voltage: 3750 V AC Input to Output
- Dimensions (L x W x H): 244 mm x 71 mm x 37.5 mm
- Weight: approx. 1.22 kg
- Safety & EMC Certificates: UL8750 (Type HL), EN61347-1, EN61347-2-13, BIS IS15885, EAC, CE
- Ingress Protection / Housing: IP67 Metal Housing
- Warranty: 5 Years
Information about MEAN WELL ELG-200-42DA
Through native support for the DALI control standard (IEC 62386), the MEAN WELL ELG-200-42DA driver enables sophisticated lighting automation across both Constant Voltage and Constant Current output modes. Housed inside a fully encapsulated IP67-rated metal enclosure for total protection against dust and moisture, it performs reliably across an extended −40 °C to +90 °C case temperature working environment. Built to endure harsh industrial conditions with 5G vibration resistance, this 42V DALI power supply is ideally suited for smart architectural lighting, high-bay luminaires, and Class I, Division 2 hazardous locations backed by UL8750 Type HL certification and a full 5-year warranty.
