Technical Information & Details for MEAN WELL HLG-60H-C700AB LED Driver Rated Power: 70 W Output Voltage (Constant Current Region): 50 – 100 V DC Rated Current: 700 mA Current Adjustable Range: 420 – 700 mA (via internal potentiometer) Input Voltage Range: 90 – 305 V AC / 127 – 431 V DC Efficiency: Up to 90.5 % Power Factor: PF ≥ 0.98 / 115 VAC, PF ≥ 0.96 / 230 VAC IP Rating: IP65 (protection against water jets and dust) Operating Temperature: −40 °C to +80 °C (case temperature) Dimming Functions: 3-in-1 dimming (1-10V, PWM, Resistance) + Potentiometer Safety Standards: UL8750, EN61347-1, EN61347-2-13, IP65 Dimensions (L x W x H): 171 mm x 61.5 mm x 36.8 mm Weight: 0.73 kg Manufacturer Warranty: 7 Years Information about the MEAN WELL HLG-60H-C700AB The MEAN WELL HLG-60H-C700AB is the high-end multipurpose solution in the constant current LED driver market, specifically engineered for applications requiring both installation-side calibration and end-user control. As an "AB-type" variant, it features a unique dual-adjustment mechanism: an internal potentiometer allows for manual current limit setting between 420 mA and 700 mA, while the integrated 3-in-1 dimming interface provides full compatibility with remote control systems using 1-10V DC, 10V PWM, or resistance signals. This level of versatility ensures that lighting systems can be perfectly tuned to the specific thermal and optical requirements of the LED array while maintaining the flexibility of smart-lighting integration. Its ruggedized metal housing with IP65 rating ensures high durability against moisture and dust, making it ideal for high-bay lighting, greenhouse environments, and outdoor architectural designs. Technologically, the driver excels with a peak efficiency of up to 90.5% and a built-in active PFC function that ensures a power factor of over 0.98, effectively reducing harmonic distortion and energy waste. The driver is designed for mission-critical installations, utilizing a fanless thermal design that operates silently via free air convection across a wide temperature spectrum from -40 °C to +80 °C. By eliminating active cooling components, the unit significantly enhances system reliability, boasting a typical lifetime of over 62,000 hours. The inclusion of comprehensive protection against short circuits, over-voltage, and over-temperature provides an additional layer of security for high-value LED modules. Backed by a prestigious 7-year manufacturer warranty, the HLG-60H-C700AB represents a superior, long-term investment for industrial and professional lighting infrastructure where performance and maintenance-free operation are paramount.

Technical Information & Details for MEAN WELL HLG-80H-C350AB LED Driver Rated Power: 89.95 W Output Voltage (Constant Current Region): 128 V – 257 V DC Rated Current: 350 mA Input Voltage Range: 90 – 305 V AC / 127 – 431 V DC, 47 – 63 Hz Efficiency: 91.5 % Current Ripple: 8.0% max. Inrush Current: 60 A (twidth=410µs) at 230 V AC Power Factor (PF): ≥ 0.96 @ full load Operating Temperature: -40 °C to +80 °C Case Temperature Cooling: fanless natural convection Protections: Short circuit, Over voltage, Over temperature IP Rating: IP65 (dust-tight and protected against water jets) Control Options: 3-in-1 dimming (1-10V, PWM, resistance) + internal potentiometer Withstand Voltage: 3.75 kV AC between input and output Dimensions (L x W x H): 195.6 mm x 61.5 mm x 38.8 mm Weight: approx. 840 g Safety & EMC Certificates: UL8750, EN61347-1, EN61347-2-13, IP65, EAC, CE Manufacturer Warranty: 7 Years Information on the MEAN WELL HLG-80H-C350AB The MEAN WELL HLG-80H-C350AB is a premium 90W LED power supply that offers the ultimate flexibility in Constant Current control. This AB-Type model stands out by featuring dual-mode adjustment capability, allowing users to fine-tune the output current manually via an internal potentiometer (ranging from 210mA to 350mA) while simultaneously supporting 3-in-1 dimming protocols, including 1-10V DC, PWM signal, and resistance. Its rugged metal enclosure is rated at IP65, ensuring the unit remains resilient against dust and moisture in diverse environments such as outdoor architectural lighting or industrial high-bay facilities. The driver’s high efficiency of 91.5% and fanless design ensure cool, silent operation and a long operational lifespan exceeding 62,000 hours. Equipped with a built-in active PFC function and a wide input voltage range of 90-305V AC, it provides a stable and energy-efficient power source for critical LED applications like greenhouse lighting and street lamps. The industry-leading 7-year manufacturer warranty further emphasizes the high build quality and reliability, making it a trusted component for large-scale professional installations.

Technical Information & Details for MEAN WELL HLG-60H-C350AB LED Driver Rated Power: 70 W Output Voltage (Constant Current Region): 100 – 200 V DC Rated Current: 350 mA Current Adjustable Range: 210 – 350 mA (via internal potentiometer) Input Voltage Range: 90 – 305 V AC / 127 – 431 V DC Efficiency: 91 % Power Factor: PF ≥ 0.98 / 115 VAC, PF ≥ 0.96 / 230 VAC IP Rating: IP65 (protection against water jets) Operating Temperature: −40 °C to +80 °C (case temperature) Dimming Functions: 3-in-1 dimming (1-10V, PWM, Resistance) + Potentiometer Safety Standards: UL8750, EN61347-1, EN61347-2-13, GB19510.1 Dimensions (L x W x H): 171 mm x 61.5 mm x 36.8 mm Weight: 0.73 kg Manufacturer Warranty: 7 Years Detailed Information about MEAN WELL HLG-60H-C350AB The MEAN WELL HLG-60H-C350AB represents the pinnacle of LED driver versatility, specifically designed for professional lighting applications that demand both manual calibration and automated control. As part of the prestigious AB-type series, this driver features a dual-mode adjustment system: an internal potentiometer located under a protective rubber stopper for manual current tuning, and a 3-in-1 dimming interface for remote integration. This allows installers to pre-set the maximum current between 210 mA and 350 mA to perfectly match the thermal and luminous requirements of the LED array, while still providing the end-user with seamless dimming capabilities via 1-10V DC, 10V PWM signals, or external resistance. The rugged metal housing is IP65 rated, ensuring the unit is shielded against dust and low-pressure water jets, making it exceptionally reliable for industrial bay lighting and architectural installations. Engineering excellence is evident in its electrical performance, featuring a high efficiency of 91% and a built-in active Power Factor Correction (PFC) function that optimizes energy consumption and stabilizes the electrical load. The driver's fanless design relies entirely on natural air convection for cooling, enabling a silent and maintenance-free operation even in extreme environments where case temperatures reach +80 °C. This resilience is further bolstered by comprehensive protection circuitry against short-circuits, over-voltage, and over-temperature conditions. With a typical lifetime exceeding 62,000 hours and an industry-leading 7-year manufacturer warranty, the HLG-60H-C350AB is a high-end investment for critical lighting infrastructure such as greenhouse systems, harbor lighting, and high-mast stadium fixtures, ensuring long-term performance and minimal total cost of ownership.
