ELG-240-24AB-3Y

Technical Information & Details for MEAN WELL ELG-100-24-3Y Power Supply Output Power: 96 W (at 200–305 V AC) / 70 W (at 100–180 V AC) Output Voltage: 24 V DC Output Current: 4.0 A Input Voltage Range: 100 – 305 V AC / 142 – 431 V DC, 47 – 63 Hz Efficiency: Up to 90% Ripple & Noise: ≤ 200 mVp-p Inrush Current: COLD START 60 A @ 230 V AC No Load / Standby Power: < 0.5 W Operating Temperature: −40 °C to +90 °C (Case temperature Tcase) Cooling: Fanless free air convection Protections: Short circuit (Hiccup mode), Overload (Constant current limiting), Over voltage, Over temperature Isolation Voltage: 3750 V AC between Input and Output Ingress Protection / Housing: IP67, Metal housing with Protective Earth (PE) Dimensions (L x W x H): 199 mm x 63 mm x 35.5 mm Weight: approx. 850 g Safety & EMC Standards: UL8750 (Type HL), EN61347-1, EN61347-2-13, EN55015, EAC, CB, CE Operating Mode: Dual Constant Voltage (CV) + Constant Current (CC) Mode AC Input Connection: 3-wire AC input cable with PE ground wire (3Y-Type) Warranty: 5 Years Information about MEAN WELL ELG-100-24-3Y Engineered for high-efficiency outdoor and industrial LED applications, the MEAN WELL ELG-100-24-3Y delivers flexible driving capability via its dual Constant Voltage + Constant Current Mode output. Built inside a rugged metal enclosure rated to IP67 ingress protection, it ensures complete resistance against dust and water immersion. The unit excels under harsh climatic conditions with an extended case operating temperature range of -40 °C to +90 °C. Designed as a 3Y-model, it features a 3-wire AC input cable including a dedicated PE safety ground wire for direct protective earth connection. Furthermore, its UL8750 (Type HL) rating permits installation in hazardous (Class I, Division 2) locations such as chemical plants and heavy industrial facilities. Backed by a 5 years manufacturer warranty, this driver provides long-term stability for architectural, bay, and street lighting installations.

In: 100-305VAC 47-63Hz 142-431VDC / Eff. 92% / 140x63x32mmOut: 24V 4A, 2-4A strom einstellbar , Arbeitet im CC und CV modus, IP67

Technical Information & Details for MEAN WELL ELG-200-24B-3Y Power Supply Output Power: 199.68 W Output Current: 8.33 A Output Voltage: 24 V DC Input Voltage Range: 100 – 305 V AC / 142 – 431 V DC, 47 – 63 Hz Efficiency: up to 92% Ripple & Noise: ≤ 200 mVp-p Inrush Current: max. 60 A @230 VAC Standby Power Consumption: < 0.5 W Operating Temperature: −40 °C to +90 °C (case temperature Tcase) Cooling: fanless free air convection Protections: short circuit, over current, over voltage, over temperature Overvoltage Category: OVC II Isolation Voltage: 3750 V AC input to output Dimensions (L x W x H): 244 mm x 71 mm x 37.5 mm Weight: approx. 1220 g Safety & EMC Certificates: CE, UL8750 (Type HL), EN61347-1, EN61347-2-13, EAC, BIS Protection Rating & Feature: IP67, 3-in-1 dimming function, 3-wire AC input with PE (3Y) Manufacturer Warranty: 5 years Information on the MEAN WELL ELG-200-24B-3Y Combining heavy-duty outdoor durability with precise output control, the MEAN WELL ELG-200-24B-3Y serves as an ideal LED driver for high-demand 24V industrial lighting systems. It features versatile 3-in-1 dimming technology, allowing seamless light adjustment via 0–10VDC, 10V PWM, or resistance inputs. Encapsulated in a rugged aluminum housing rated to IP67 water and dust ingress protection, the unit includes a 3-wire input cable with a dedicated PE ground wire for maximum safety compliance. Its hazardous-location Type HL approval makes it suitable for Class I, Division 2 installations, while built-in 5G vibration resistance protects against extreme mechanical shock. With high operational efficiency, this power supply is designed for continuous duty and is supported by a 5-year warranty.

Technische Eigenschaften des MEAN WELL ELG-300-12A Leistung: 300W Spannung: 24V Aluminiumgehäuse Integriertes PFC Standby Ladeverbrauch <0,5W IP67 Allgemeine Lebensdauer >50.000Std. 5 Jahre Garantie Produktbeschreibung zur MEAN WELL ELG-300 Serie Bei der MEAN WELL ELG-300 Serie handelt es sich um 300W AC/DC LED Netzteile, die im dualen Modus einen Konstantstrom- und Konstantspannungsausgang unterstützen. Die ELG-300 Netzteile arbeiten mit einem 180~295VAC Eingangsbereich und bieten verschiedene Ausgangsspannungen im Bereich von 12V bis 24V an. Dank des 90% hohem Wirkungsgrads und dem lüfterlosen Design kann die Serie unter freier Luftkonvektion im Temperaturbereich von -40°C bis +85°C betrieben werden. Durch das verwendete Aluminiumgehäuse und den Schutzklassen IP65/67 finden MEAN WELL ELG-300 Netzteile Anwendung sowohl Indoor-, als auch im Outdoorbereich.
