Technical Information & Details for MEAN WELL HLG-600H-36AB Power Supply
- Output Power: 601.2 W
- Output Voltage: 36 V DC
- Output Current: 16.7 A
- Input Voltage Range: 90 – 305 V AC / 127 – 431 V DC, 47 – 63 Hz
- Efficiency: up to 95.5 %
- Ripple & Noise: ≤ 250 mVp-p
- Inrush Current: max. 70 A @ 230 VAC (Cold Start)
- Standby Power Consumption: < 0.5 W (at remote off)
- Operating Temperature: -40 °C to +90 °C (Case Temperature)
- Cooling: Fanless natural convection
- Protections: Short circuit, Over current, Over voltage, Over temperature
- IP Rating: IP65 (Dust and water splash protection)
- Isolation Voltage: 3750 V AC between input and output
- Dimensions (L x W x H): 280 mm x 144 mm x 48.5 mm
- Weight: approx. 3.9 kg
- Certificates: UL8750, ENEC, IP65, EAC, CE, Type HL
- Control Features: 3-in-1 dimming (0-10V, PWM, resistance) & Potentiometer
- Manufacturer Warranty: 7 Years
Information about the MEAN WELL HLG-600H-36AB
The MEAN WELL HLG-600H-36AB stands as a premium 600W power solution, meticulously engineered for high-wattage industrial LED applications and complex power distribution systems. The AB-Type specification provides a highly versatile control interface, combining on-board potentiometers for manual voltage and current calibration with an integrated 3-in-1 dimming protocol. This allowing seamless integration with automated controllers via 0-10V, PWM, or resistance signals, making it an ideal candidate for stadium lighting, architectural facade illumination, and high-precision horticultural LED setups where performance stability is critical.
Constructed for longevity in challenging environments, this power supply features a rugged aluminum housing with an IP65 rating, ensuring superior protection against moisture and debris. Its sophisticated thermal management allows for a completely fanless design while maintaining an efficiency of up to 95.5%, effectively reducing heat generation and mechanical failure points. With a typical lifetime of over 62,000 hours and an industry-leading 7-year manufacturer warranty, the HLG-600H-36AB delivers exceptional operational security and high energy savings for large-scale professional lighting installations worldwide.
