• Output Power: 100.8 W (at 200–305 V AC) / 70 W (at 100–180 V AC)
• Output Voltage (Constant Current Region): 48 – 96 V DC
• Output Current: 1050 mA
• Input Voltage Range: 100 – 305 V AC / 142 – 431 V DC, 47 – 63 Hz
• Efficiency: up to 91%
• Current Ripple: 5.0% max.
• Inrush Current: 40 A / 230 V AC (Cold Start)
• No Load / Standby Power Consumption: < 0.5 W
• Operating Temperature (Case): −40 °C to +90 °C (Tcase)
• Cooling: fanless free air convection
• Protections: Short Circuit, Over Voltage, Over Temperature
• Surge Immunity: 6 kV / 4 kV (Line-Earth / Line-Line)
• Isolation Voltage: 3750 V AC (Input/Output)
• Dimensions (L x W x H): 199 mm x 63 mm x 35.5 mm
• Weight: approx. 850 g
• Safety & EMC Certificates: UL8750 (Type HL), EN61347-1, EN61347-2-13, BIS IS15885, CB, CE, EAC
• Protection Rating: IP67
• Manufacturer Warranty: 5 years

Product Overview for the MEAN WELL ELG-100-C1050B-3Y

Empowering flexible analog lighting architectures through its native 3-in-1 dimming capability (supporting 1-10V DC, PWM signals, and external potentiometers), the MEAN WELL ELG-100-C1050B-3Y constant current driver delivers exceptional operational control. Line input is safely connected using a standard 3-core cable featuring dedicated earth grounding. Built to withstand punishing outdoor conditions, the internal circuitry is completely potted inside an aluminum housing carrying an IP67 ingress protection rating. Structural integrity is heavily reinforced to neutralize continuous mechanical stress, comfortably absorbing up to 5G vibration forces. Reinforced by hazardous location certification under UL8750 Type HL guidelines and backed by a comprehensive 5-year warranty, this unit guarantees dependable long-term performance.
