Technical Information & Details for the MEAN WELL ELG-100-C350B-3Y Power Supply
- Output Power: 99.75 W
- Output Voltage Range: 143 – 286 V DC (Constant Current Region)
- Output Current: 350 mA
- Input Voltage Range: 100 – 305 V AC / 142 – 431 V DC, 47 – 63 Hz
- Efficiency: up to 90%
- Current Ripple: 5.0% max. at rated current
- Inrush Current: max. 40 A at 230 V AC
- Standby Power Consumption: < 0.5 W
- Operating Temperature: Case temperature (Tcase) −40 °C to +90 °C
- Cooling: fanless free air convection
- Protection Functions: Short circuit, over voltage, over temperature
- Ingress Protection: IP67 / IP65 rated for indoor or outdoor installations
- Withstand Voltage: 3.75 kV AC between input and output
- Dimensions (L x W x H): 199 mm x 63 mm x 35.5 mm
- Weight: approx. 0.85 kg
- Safety & EMC Standards: UL8750, CSA, EN61347, EAC, CE
- Dimming Option: 3 in 1 dimming function (0–10 V DC, 10 V PWM signal, and resistance)
- Manufacturer Warranty: 5 years
Information about the MEAN WELL ELG-100-C350B-3Y
Engineered for high-performance LED systems, the ELG-100-C350B-3Y delivers exceptional reliability across harsh environments. Built to handle demanding applications, it features a rugged IP67 enclosure rating, an integrated 3 in 1 dimming control mechanism, and a powerful 99.75 W constant current output. Backed by a comprehensive 5 years manufacturer warranty, this driver ensures dependable, energy-efficient operation for industrial lighting setups.
