• Rated Power: 299.6 W
• Constant Current Region: 214 – 428 V DC
• Rated Current: 700 mA
• Input Voltage Range: 90 – 305 V AC / 127 – 417 V DC, 47 – 63 Hz
• Efficiency: up to 94 %
• Current Ripple: max. 5.0 % @ rated current
• Inrush Current: max. 70 A @ 230 V AC (Cold Start)
• Leakage Current: < 0.75 mA / 277 V AC
• Operating Temperature: −40 °C to +85 °C (Tcase)
• Cooling: fanless free air convection
• Protection Functions: Short Circuit, Over Voltage, Over Temperature
• Power Factor (PF): ≥ 0.98 / 115 V AC, ≥ 0.95 / 230 V AC at full load
• Withstand Voltage: 3.75 KV AC between Input and Output
• Dimensions (L x W x H): 252 mm x 90 mm x 43.8 mm
• Weight: approx. 1.88 kg
• Safety & EMC Certificates: UL8750, ENEC EN61347-1, IP67 approved
• Dimming Function: Built-in 3-in-1 dimming (0-10VDC, 10V PWM, resistance)
• Manufacturer Warranty: 7 Years

Information about MEAN WELL HLG-320H-C700B

The MEAN WELL HLG-320H-C700B is a high-performance, industrial-grade LED driver engineered for maximum reliability in high-voltage constant current applications. This B-Type variant is specifically distinguished by its integrated 3-in-1 dimming interface, allowing for seamless brightness control via 0-10V, PWM signal, or external resistance, providing installers with ultimate flexibility for smart lighting and automation. With a thermal-efficient fanless design and a peak efficiency of 94%, this driver significantly reduces energy waste and heat accumulation, which is critical for extending the service life to over 62,000 hours. The ruggedized metal enclosure features an IP67 rating, ensuring total protection against dust and temporary immersion, making it the perfect solution for harsh environments such as harbor lighting, greenhouse systems, and high-mast installations. Its ability to operate across a wide temperature range from -40°C to +85°C and its Type HL classification for hazardous locations guarantee safety and performance where other drivers fail. Complemented by a built-in active PFC function and a 7-year manufacturer warranty, the HLG-320H-C700B offers a premium, future-proof solution for demanding LED architectural and industrial projects worldwide.
