• Output Power: 200.2 W
• Output Voltage Range: 71 – 143 V DC
• Output Current: 1400 mA
• Dimming Function: 3-in-1 dimming (0-10VDC, 10V PWM signal, resistance)
• Input Voltage Range: 90 – 305 V AC / 127 – 431 V DC
• Efficiency: 94 %
• Power Factor: PF ≥ 0.98 / 115 VAC, PF ≥ 0.95 / 230 VAC
• Current Ripple: max. 5.0%
• Operating Temperature: −40 °C to +90 °C (T-case)
• Cooling: Fanless natural convection
• Ingress Protection: IP67 rated (fully encapsulated)
• Protection Functions: Short circuit, Over voltage, Over temperature
• Isolation Voltage: 3750 V AC between Input and Output
• Dimensions (L x W x H): 228 mm x 68 mm x 38.8 mm
• Weight: 1.15 kg
• Safety Standards: UL8750, EN61347-1, EN61347-2-13, CE, EAC
• Typical Lifetime: > 62,000 hours
• Manufacturer Warranty: 7 years

Information about the MEAN WELL HLG-185H-C1400B

The MEAN WELL HLG-185H-C1400B is a high-performance 200W AC/DC LED driver designed for constant current mode operation in sophisticated lighting environments. The core strength of the "B" type variant lies in its versatile 3-in-1 dimming methodology, which provides engineers and designers with the flexibility to adjust light output via 0-10VDC, 10V PWM signals, or external resistance. This functionality is ideal for smart lighting applications where centralized control is required, all while maintaining an extraordinary efficiency of 94% to ensure energy-saving performance and reduced thermal stress within the robust metal enclosure.

Equipped with a full IP67 ingress protection rating, the power supply is completely sealed against dust and water, making it a premier choice for heavy-duty outdoor installations such as LED street lamps, high-mast harbor lighting, and architectural floodlights. The fanless design utilizes natural air convection for cooling, allowing for stable and silent operation across a wide temperature range from -40 °C to +90 °C. Supported by built-in active PFC technology and a comprehensive 7-year manufacturer warranty, the HLG-185H-C1400B provides an exceptionally reliable and long-lasting power solution that minimizes maintenance costs for professional lighting infrastructure.
