Technical Information & Details for MEAN WELL HLG-185H-C1050B Power Supply
- Output Power: 200 W
- Output Voltage Range: 95 – 190 V DC
- Output Current: 1050 mA
- Dimming Function: 3-in-1 dimming (0-10VDC, 10V PWM signal, resistance)
- Input Voltage Range: 90 – 305 V AC / 127 – 431 V DC
- Efficiency: 94 %
- Power Factor: PF ≥ 0.98 / 115 VAC, PF ≥ 0.95 / 230 VAC
- Current Ripple: max. 5.0%
- Operating Temperature: −40 °C to +90 °C (T-case)
- Cooling: Fanless natural convection
- Ingress Protection: IP67 rated (fully encapsulated)
- Protection Functions: Short circuit, Over voltage, Over temperature
- Isolation Voltage: 3750 V AC (Input to Output)
- Dimensions (L x W x H): 228 mm x 68 mm x 38.8 mm
- Weight: 1.15 kg
- Safety Standards: UL8750, EN61347-1, EN61347-2-13, CE, EAC
- Typical Lifetime: > 62,000 hours
- Manufacturer Warranty: 7 years
Information about the MEAN WELL HLG-185H-C1050B
The MEAN WELL HLG-185H-C1050B is a high-performance 200W AC/DC LED driver engineered for constant current mode operation in mission-critical lighting applications. The defining strength of the "B" type model is its versatile 3-in-1 dimming methodology, which provides lighting designers with the flexibility to control current levels via 0-10VDC, 10V PWM signals, or external resistance. Boasting an outstanding efficiency of 94%, this driver ensures energy-efficient operation and minimal heat dissipation, which is further enhanced by its robust active PFC function and high-quality aluminum housing design.
Equipped with a full IP67 ingress protection rating, the power supply is completely sealed against dust and water, making it the ideal choice for harsh environment installations such as high bay lighting, outdoor floodlights, and street lighting systems. Its fanless design allows for silent operation and thermal stability across a wide temperature range from -40 °C to +90 °C. Supported by an industry-leading 7-year manufacturer warranty and a typical lifetime of over 62,000 hours, the HLG-185H-C1050B delivers an exceptionally reliable and long-lasting power solution for professional lighting infrastructure.
