• Output power: 75.6 W
• Output voltage: 42 V DC
• Output current: 1.8 A
• Input voltage range: 100 – 305 V AC / 142 – 431 V DC, 47 – 63 Hz
• Efficiency: up to 90 %
• Ripple & noise: ≤ 250 mVp-p
• Inrush current: max. 50 A @ 230 VAC
• No load power consumption: < 0.5 W
• Operating temperature: −40 °C to +85 °C
• Cooling: fanless natural convection
• Protection functions: short circuit, overload, over voltage, over temperature
• Ingress protection: IP67
• Isolation voltage: 3750 V AC between input and output
• Dimensions (L x W x H): 180 mm x 63 mm x 35.5 mm
• Weight: approx. 800 g
• Safety & EMC certifications: UL8750, CSA C22.2 No. 250.13-12, EN 61347-1, EN 61347-2-13, EN 62384, EAC, KC
• Dimming: 3-in-1 (1-10VDC, 10V PWM, Resistance)
• Manufacturer warranty: 5 years

Information about the MEAN WELL ELG-75-42B-3Y

The MEAN WELL ELG-75-42B-3Y combines adjustable output parameter flexibility with universal 3-in-1 dimming capability (1-10V, 10V PWM, resistance) in a professional 75 W LED power supply featuring 3-wire protective earth connection. This versatile dimming compatibility enables seamless integration into virtually any lighting control system, while factory-adjustable potentiometers for Io/Vo provide precise matching to specific LED configurations. The high efficiency up to 90 % and completely fanless design ensure maximum energy efficiency and silent operation.

With IP67 protection, rugged metal housing, and extreme temperature range from −40 °C to +85 °C, the ELG-75-42B-3Y is perfect for professional applications including architectural lighting, stage lighting, area lighting, and systems requiring variable light control. The combination of flexible dimming, adjustable constant voltage/constant current characteristics, comprehensive protection, and dedicated grounding connection delivers maximum system reliability. The 5-year manufacturer warranty and 50,000+ hour typical lifetime confirm the superior industrial quality of this universally deployable LED driver.
