• Output Power: 75.6 W
• Output Voltage: 36 V DC
• Output Current: 2.1 A
• Input Voltage Range: 100 – 305 V AC / 142 – 431 V DC, 47 – 63 Hz
• Efficiency: up to 89%
• Ripple & Noise: ≤ 250 mVp-p
• Inrush Current: max. 50 A @ 230 VAC
• Standby Power Consumption: < 0.5 W
• Operating Temperature: −40 °C to +85 °C
• Dimming Function: 3-in-1 (0-10 V DC, 10 V PWM signal, resistance)
• Cooling: fanless natural convection
• Protections: Short circuit, overcurrent, overvoltage, overtemperature
• IP Rating: IP67
• Isolation Voltage: 3750 V AC between input and output
• Dimensions (L x W x H): 180 mm x 63 mm x 35.5 mm
• Weight: approx. 800 g
• Safety & EMC Certificates: CE, ENEC, TUV, CB, EAC, UKCA
• Power Factor Correction (PFC): Active
• Manufacturer Warranty: 5 Years

Information about the MEAN WELL ELG-75-36B

The MEAN WELL ELG-75-36B is a premium LED power supply that seamlessly combines extreme reliability with exceptional flexibility for professional lighting installations. The defining unique characteristic of this specific "B" variant is its advanced 3-in-1 dimming function, which allows for precise brightness control via 0-10V DC, a 10V PWM signal, or resistance, providing maximum adaptability for smart home integrations and complex architectural lighting setups. Encased in a heavy-duty metal enclosure that proudly carries a strict IP67 rating, the internal electronics are hermetically sealed, making the unit completely dust-tight and highly water-resistant for permanent and safe outdoor applications. Driven by state-of-the-art active Power Factor Correction (PFC), this robust LED driver achieves a remarkable energy efficiency of up to 89%, significantly minimizing daily energy consumption while delivering stable, flicker-free performance in dual constant voltage and constant current mode.

Engineered to withstand the toughest electrical environments, this power supply features an ultra-wide input voltage range of 100 to 305 V AC, ensuring flawless operation even when faced with massive power fluctuations on a global scale. The highly efficient fanless design relies entirely on natural convection cooling, guaranteeing a completely silent operation across an extreme operating temperature range of −40 °C to +85 °C, which effectively eliminates the risk of unexpected mechanical fan failure. To ensure absolute safety and protect your valuable LED arrays, the device is fully equipped with comprehensive protection mechanisms that immediately respond to short circuits, overcurrent, overvoltage, and overtemperature emergencies. Backed by an industry-leading 5-year manufacturer warranty, the MEAN WELL ELG-75-36B stands out as the ultimate, long-lasting power solution for commercial floodlights, street lamps, and demanding industrial lighting projects.
