• Output Power: 60 W
• Output Voltage: 12 V DC
• Output Current: 5 A
• Input Voltage Range: 100 – 305 V AC / 142 – 431 V DC, 47 – 63 Hz
• Efficiency: up to 86 %
• Ripple & Noise: ≤ 150 mVp-p
• Inrush Current: max. 50 A @ 230 VAC
• Standby Power Consumption: < 0.5 W
• Operating Temperature: −40 °C to +85 °C (Case Temperature)
• Cooling: fanless natural convection
• Protections: Short circuit, Over current, Over voltage, Over temperature
• Isolation Voltage: 3750 V AC between Input and Output
• Dimensions (L x W x H): 180 mm x 63 mm x 35.5 mm
• Weight: approx. 800 g
• Safety & EMC Certificates: UL8750, EN61347, EAC, KC, CE
• Special Features: IP67 rating, 3-in-1 dimming function
• Manufacturer Warranty: 5 Years

Information about the MEAN WELL ELG-75-12B

The MEAN WELL ELG-75-12B is an advanced, highly durable 60W AC/DC LED driver that stands out for its intelligent lighting control capabilities. Housed in a robust, IP67-rated metal enclosure for ultimate protection against dust and water immersion, this specialized "B-Type" model features a highly sought-after 3-in-1 dimming function. This allows users to seamlessly adjust the constant current output level using a 0~10V DC, 10V PWM signal, or a simple resistance dimmer, making it incredibly versatile for smart lighting grids. Engineered for extreme reliability in harsh settings, it easily accommodates a broad input voltage range of 100 to 305V AC and safely operates in severe case temperatures ranging from -40°C all the way up to +85°C.

A major strength of the ELG-75-12B power supply is its commitment to energy conservation, boasting an impressive efficiency of up to 86% alongside an ultra-low standby power consumption of less than 0.5W. Beyond its energy-saving metrics, it provides absolute peace of mind through a fully integrated suite of automatic recovery protections against short circuits, overcurrent, overvoltage, and overheating. Supported by an industry-leading 5-year manufacturer warranty and strict adherence to global safety and EMC regulations, this rugged, fanless driver is the premier solution for LED street lighting, smart architectural illumination, and demanding high-bay applications.
