HLG-120H-48B

Quantity	Unit price
from 1	€48.70*
from 5	€46.40*
from 10	€44.40*
from 20	€43.10*

Prices excl. VAT plus shipping costs zzgl. Versandkosten

Available, delivery time: 1-3 days

Product number: 15266

Product information "HLG-120H-48B"

Technical Information & Details for the MEAN WELL HLG-120H-48B Power Supply

Rated Power: 120 W
Output Voltage (DC): 48 V
Rated Current: 2.5 A
Input Voltage Range: 90 – 305 V AC / 127 – 431 V DC
Efficiency (typ.): 93 %
Ripple & Noise (max.): 200 mVp-p
Constant Current Region: 24 – 48 V
Operating Temp. (Case): −40 °C to +80 °C
IP Rating: IP67 (fully dust-tight and waterproof)
Dimming Technology: 3-in-1 dimming (1–10V DC, 10V PWM signal, or resistance)
Manufacturer Warranty: 7 Years

Information about the MEAN WELL HLG-120H-48B

The MEAN WELL HLG-120H-48B is a high-performance 120W LED driver engineered for smart lighting applications that require remote brightness control and extreme durability. As a "B-Type" model, it features a dedicated dimming wire for integrated 3-in-1 dimming. This allows users to regulate the light intensity via a 1–10V DC signal, a 10V PWM signal, or external resistance, making it ideal for 48V building automation systems.

Designed for mission-critical reliability, the HLG-120H-48B features a fully potted metal enclosure with an IP67 rating. This ensures the unit is completely sealed against dust and moisture, allowing it to function even after temporary immersion in water. This robust level of protection makes it the premier choice for high-exposure outdoor installations, hazardous industrial locations, and professional 48V LED arrays.

Technically, the driver utilizes a dual-mode constant voltage and constant current output, providing 93% efficiency and built-in active Power Factor Correction (PFC). The fanless thermal design utilizes natural air convection for cooling, facilitating completely silent operation and a lifespan exceeding 62,000 hours. Backed by an industry-leading 7-year warranty, the HLG-120H-48B is a top-tier solution for dimmable street lighting and large-scale greenhouse projects.

Weiterführende Links zu "HLG-120H-48B"

Fragen zum Artikel?
Weitere Artikel von MEAN WELL

Verfügbare Downloads

Download HLG-120H Datasheet

Eigenschaften für "HLG-120H-48B"

Approval:	CB, CCC, CE, MM, SELV, TÜV, UL
Dimming:	3 in 1 dimming (1-10V, Poti, PWM)
Efficiency:	93,5 %
Height:	38,8
Length:	220
Protection Class:	Class I
Protection Rating:	IP67
Rated current:	2,5
Series:	HLG
Voltage:	48 VDC
Warranty:	7 years
Wattage:	120 W
Weight:	1,12kg
Width:	68
