• Output Power: 96.12 W (at 200–305 V AC) / 70 W (at 100–180 V AC)
• Output Voltage: 54 V DC
• Output Current: 1.78 A (dimmable 0.89–1.78 A)
• Input Voltage Range: 100 – 305 V AC / 142 – 431 V DC, 47 – 63 Hz
• Efficiency: Up to 91%
• Ripple & Noise: ≤ 350 mVp-p
• Inrush Current: COLD START 60 A @ 230 V AC
• No Load / Standby Power: < 0.5 W
• Operating Temperature: −40 °C to +90 °C (Case temperature Tcase)
• Cooling: Fanless free air convection
• Protections: Short circuit (Hiccup mode), Overload (Constant current limiting), Over voltage, Over temperature
• Isolation Voltage: 3750 V AC between Input and Output
• Dimming Control: 3-in-1 dimming (0–10 V DC, 10 V PWM signal, 100 kΩ resistance)
• Ingress Protection / Housing: IP67, Metal housing
• Dimensions (L x W x H): 199 mm x 63 mm x 35.5 mm
• Weight: approx. 850 g
• Safety & EMC Standards: UL8750 (Type HL), EN61347-1, EN61347-2-13, EN55015, EAC, CB, CE
• AC Input Connection: Standard 2-wire AC input cable
• Warranty: 5 Years

Information about MEAN WELL ELG-100-54B

Continuous brightness management is made possible on the MEAN WELL ELG-100-54B through its versatile 3-in-1 dimming interface (0–10V, PWM, resistance) for customized illumination settings. Designed inside a heavy-duty IP67 potted metal case, internal components remain fully insulated from particulate pollution and liquid penetration. Heat is dissipated naturally via convection without moving mechanical parts, maintaining dead-silent operation across case operating temperatures from -40 °C to +90 °C. Built to conform with UL8750 (Type HL) standards for Class I, Division 2 hazardous locations, this unit comes backed by a 5 years manufacturer warranty.
