S-100F-5 Auslaufmodell

Technical Specifications & Details for MEAN WELL LRS-100-5 Power Supply Output Power: 90 W Output Voltage: 5 V DC Output Current: 18 A Input Voltage Range: 85 – 264 V AC / 120 – 373 V DC, 47 – 63 Hz Efficiency: up to 86% Ripple & Noise: ≤ 80 mVp-p Inrush Current: max. 50 A @230 VAC No Load Power Consumption: < 0.3 W Operating Temperature: -30 °C to +70 °C Cooling: Free air convection Protection Functions: Short circuit, Overload, Over voltage Overvoltage Category: OVC III Isolation Voltage: 3.75 kV AC between input and output Dimensions (H x W x D): 30 mm x 97 mm x 129 mm Weight: approx. 340 g Safety & EMC Certificates: CE, UL 62368-1, TUV, CB, EAC LED Indicator: Power On Indicator Manufacturer Warranty: 3 Years Information on the MEAN WELL LRS-100-5 The MEAN WELL LRS-100-5 is a highly reliable 90W single-output enclosed power supply specifically engineered for modern industrial applications where space and efficiency are paramount. Featuring a slim 30mm low-profile design, this unit fits perfectly into 1U chassis configurations, allowing for high-density hardware layouts without thermal complications. The power supply is built to endure demanding environments, boasting a 5G vibration resistance and a specialized internal layout that allows for efficient heat dissipation through natural air convection, eliminating the need for noisy mechanical fans. A key technical strength of the LRS-100-5 is its strict adherence to Over Voltage Category III (OVC III) standards, providing a higher level of safety for fixed installations in industrial panels. With a stabilized 5V DC output delivering up to 18A, it serves as an ideal power source for LED displays, control systems, and complex logic circuits. The unit’s extremely low no-load power consumption of less than 0.3W ensures that the system meets the most stringent global energy-saving regulations, while the 3.75kV AC isolation voltage guarantees a secure separation between input and output for maximum equipment protection.
