Technical Information & Details for the MEAN WELL HRP-100-7.5 Power Supply
- Output Power: 101.3 W
- Output Voltage: 7.5 V DC
- Output Current: 13.5 A
- Input Voltage Range: 85 – 264 V AC / 120 – 370 V DC, 47 – 63 Hz
- Efficiency: 84 %
- Ripple & Noise: ≤ 100 mVp-p
- Inrush Current: max. 35 A @115 VAC / 65 A @230 VAC
- No Load Power Consumption: < 0.5 W
- Operating Temperature: −40 °C to +60 °C
- Cooling: Free air convection
- Protection Functions: Short circuit, Overload, Over voltage, Over temperature (optional)
- Isolation Voltage: 3000 V AC between input and output
- Dimensions (L x W x H): 159 mm x 97 mm x 38 mm
- Weight: 0.56 Kg
- Safety & EMC Certificates: UL62368-1, TUV BS EN/EN62368-1, AS/NZS62368.1, EAC
- Manufacturer Warranty: 5 Years
Information about the MEAN WELL HRP-100-7.5
The MEAN WELL HRP-100-7.5 is a high-quality 100W single-output enclosed power supply designed for demanding industrial environments where a stable 7.5V source is required. This unit features a 1U low profile design with a height of only 38mm, making it an excellent choice for installations where space is at a premium. A standout technical feature is the built-in active Power Factor Correction (PFC) function, which ensures the unit operates with high electrical efficiency and meets harmonic current requirements. Additionally, the power supply is engineered for extreme durability, capable of withstanding a 300VAC surge input for up to 5 seconds, providing critical protection against voltage spikes in the main grid.
Beyond its robust protection suite, which includes short circuit, overload, and overvoltage protections, the HRP-100-7.5 is designed for long-term reliability using 105°C long-life electrolytic capacitors. The inclusion of a built-in remote ON-OFF control allows for advanced system automation and energy management. With an impressive no-load power consumption of less than 0.5W, this model supports green energy standards and reduces operational costs. The 5-year manufacturer warranty provides significant peace of mind, confirming its status as a professional-grade component for industrial automation, control systems, and mechanical equipment.
