• Output Power: 30 W
• Output Voltage: 24 V DC
• Output Current: 1.25 A
• Input Voltage Range: 9 – 36 V DC (4:1 Wide Input)
• Efficiency: 84 %
• Ripple & Noise: ≤ 60 mVp-p
• Inrush Current: 20 A @ 24 V DC
• No-load Power Consumption: < 0.5 W
• Operating Temperature: −40 °C to +70 °C
• Cooling: fanless free air convection (half-encapsulated)
• Protections: Short circuit, Overload, Over voltage, Input reverse polarity
• Isolation Voltage: 4000 V DC reinforced isolation (I/O)
• Dimensions (L x W x H): 113 mm x 60 mm x 25 mm
• Weight: approx. 250 g
• Safety & Railway Certificates: EN50155, EN45545-2, UL 62368-1, CB, CE, EAC
• LED Indicator: Power On indicator
• Manufacturer Warranty: 3 Years

Information about the MEAN WELL RSD-30G-24

The MEAN WELL RSD-30G-24 is a professional-grade Railway DC-DC converter designed to meet the rigorous standards of the transit industry and harsh industrial applications. It fully complies with EN50155 and EN45545-2 railway standards, ensuring high reliability under extreme mechanical stress, vibration, and fire safety requirements. Its ultra-slim 1U low profile height of only 25 mm makes it an excellent fit for space-constrained modern installations.

Equipped with a versatile 4:1 wide input range from 9 to 36 V DC, the converter is compatible with various standard battery systems used in transportation. The half-encapsulated design provides essential protection against dust and high humidity while allowing for efficient cooling via natural air convection. With 4000 V DC reinforced isolation and integrated safety features like input reverse polarity protection and a constant current limiting circuit, the RSD-30G-24 offers a durable and secure power solution for telecommunications, wireless networks, and critical automation infrastructure.
