Technical Information & Details for the MEAN WELL RSP-500-3.3 Power Supply
- Output Power: 297 W
- DC Voltage: 3.3 V DC
- Rated Current: 90 A
- Input Voltage Range: 85 – 264 V AC / 120 – 370 V DC, 47 – 63 Hz
- Efficiency: up to 81 %
- Ripple & Noise: ≤ 120 mVp-p
- Inrush Current: max. 20 A @115 VAC / 40 A @230 VAC
- Working Temperature: −30 °C to +70 °C
- Cooling: built-in DC fan with continuous operation
- Protections: Short circuit, Overload, Over voltage, Over temperature
- Withstand Voltage: 3000 V AC Input-Output isolation
- Dimensions (L x W x H): 230 mm x 127 mm x 40.5 mm
- Weight: approx. 1.3 kg
- Safety & EMC Standards: UL62368-1, TUV BS EN/EN62368-1, EAC, CCC, BSMI, BIS
- LED Indicator: Power On Status
- Warranty: 3 years
Information about the MEAN WELL RSP-500-3.3
Tailored for high-current low-voltage architectures, this industrial power supply unit delivers dependable energy conversion within a compact 1U low-profile enclosure. Operating effectively within harsh environments is made possible through an expansive working temperature range from −30 °C to +70 °C, which ensures stellar thermal endurance under heavy workloads. Integrated active Power Factor Correction further enhances grid compatibility and optimizes power efficiency during continuous industrial usage.
System integration flexibility is significantly elevated by built-in remote ON-OFF control terminals alongside remote sensing voltage drop compensation lines. Complete circuit protection is achieved via a robust 3000 V AC input-to-output isolation voltage rating, shielding downstream electronics from electrical transients. Additionally, self-recovery mechanisms instantly counteract overloads, short circuits, overvoltages, and critical temperature spikes without manual intervention.
Designed for mission-critical roles in automated factory floors, laser machinery, and precision testing instruments, the unit prioritizes maximum operational uptime. Global compliance is fully demonstrated by comprehensive safety and EMC certifications including UL62368-1 and TUV. Continuous forced-air cooling via a dedicated internal DC fan maintains optimal thermal balance across all load stages.
Long-term deployment confidence is backed by a dependable 3-year manufacturer warranty, offering excellent protection for system investments. Measuring only 40.5 millimeters in height, the streamlined physical footprint allows for effortless rack-mounting inside tight industrial spaces. Combining high current delivery with advanced control features, this power supply represents an exceptional choice for modern engineering projects.
