• Output Power: 2016 W
• Output Voltage: 48 V DC
• Output Current: 42 A
• Input Voltage Range: 90 – 264 V AC / 250 – 320 V DC, 47 – 63 Hz
• Efficiency: 90.5%
• Ripple & Noise: ≤ 300 mVp-p
• Inrush Current: 50 A (Cold Start)
• No-Load Power Consumption: Not specified (Includes auxiliary power 5V/0.3A & 12V/0.8A)
• Operating Temperature: −35 °C to +70 °C
• Cooling: Forced air cooling by built-in DC fan with speed control
• Protections: Short circuit, Overload (constant current limiting), Over voltage, Over temperature
• Overvoltage Category: Not specified
• Isolation Voltage: 3000 V AC between input and output (I/P-O/P)
• Dimensions (H x W x D): 41 mm x 127 mm x 295 mm (1U Low Profile)
• Weight: approx. 2000 g
• Safety & EMC Certificates: UL62368-1, TUV BS EN/EN62368-1, EAC TP TC 004, CB, CE
• LED Indicator: Status LEDs for AC-OK, DC-OK, T-OK
• Warranty: 5 years

Information about the MEAN WELL RCP-2000-48

Designed to support demanding 48 V DC environments with up to 42 A current output, the MEAN WELL RCP-2000-48 delivers a robust 2016 W capacity inside a sleek 1U rack-mount chassis. Continuous uptime is secured by built-in OR-ing FETs that allow seamless hot-swapping during active system operations. System integrators gain full control via I²C / PMBus protocol support for real-time diagnostics, backed by an impressive isolation voltage rating of 3000 V AC to safeguard delicate electronics. Complete with a 5-year warranty, it stands out as an optimal solution for industrial automation, constant current source applications, and critical telecommunication installations.
