• Output Power: 1200 W
• Output Voltage: 12 V DC
• Output Current: 100 A
• Input Voltage Range: 90 – 264 V AC / 250 – 320 V DC, 47 – 63 Hz
• Efficiency: 86%
• Ripple & Noise: ≤ 150 mVp-p
• Inrush Current: 50 A (Cold Start)
• No-Load Power Consumption: Not specified (Includes auxiliary power 5V/0.3A & 12V/0.8A)
• Operating Temperature: −35 °C to +70 °C
• Cooling: Forced air cooling by built-in DC fan with speed control
• Protections: Short circuit, Overload (constant current limiting), Over voltage, Over temperature
• Overvoltage Category: Not specified
• Isolation Voltage: 3000 V AC between input and output (I/P-O/P)
• Dimensions (H x W x D): 41 mm x 127 mm x 295 mm (1U Low Profile)
• Weight: approx. 2000 g
• Safety & EMC Certificates: UL62368-1, TUV BS EN/EN62368-1, EAC TP TC 004, CB, CE
• LED Indicator: Status LEDs for AC-OK, DC-OK, T-OK
• Warranty: 5 years

Information about the MEAN WELL RCP-2000-12

Delivering high efficiency within a compact 1U rack-mountable front-end footprint, the MEAN WELL RCP-2000-12 power supply provides a robust 12 V DC output with up to 100 A output current. Engineeered for high-availability systems, it features integrated OR-ing FETs to support live hot-swapping and active current sharing in redundant rack setups. System integration is simplified through its I²C / PMBus protocol support for direct digital monitoring and control, while a high isolation voltage of 3000 V AC guarantees rigorous circuit protection. Backed by a comprehensive 5-year warranty, this unit is engineered to meet the demanding requirements of industrial automation, telecommunications, and electric vehicle charging systems.
