Technical Information & Details about the MEAN WELL HDR-30-24 Power Supply Output Power: 36 W Output Voltage: 24 V DC Output Current: 1.5 A Current Range: 0 – 1.5 A Input Voltage Range: 85 – 264 V AC (277 V AC operational) / 120 – 370 V DC (390 V DC operational), 47 – 63 Hz Efficiency: up to 89 % Ripple & Noise: ≤ 150 mVp-p Output Voltage Adjustment Range: 21.6 – 29 V DC Voltage Tolerance: ±1.0 % Line Regulation: ±1.0 % Load Regulation: ±1.0 % Setup, Rise Time: 500 ms, 50 ms @230 V AC / 115 V AC (full load) Hold-up Time: 30 ms @230 V AC / 12 ms @115 V AC (full load) Inrush Current: 25 A @115 V AC / 45 A @230 V AC (cold start) No-load Power Consumption: < 0.3 W Operating Temperature: −30 °C to +70 °C (with derating according to curve) Cooling: fanless free air convection Protection Functions: short circuit (hiccup mode, auto recovery), overload (constant current limiting 50–100 % of rated output voltage, auto recovery), overvoltage (shut down, re‑power to recover) Overvoltage Category: OVC III (up to 2000 m altitude) Isolation Voltage: 4000 V AC between input and output Isolation Resistance: ≥ 100 MΩ @ 500 V DC, 25 °C, 70 % RH Dimensions (W x H x D): 35 mm x 90 mm x 54.5 mm Weight: approx. 130 g Housing Material: insulating plastic, Class II Mounting: DIN rail TS35/7.5 or TS35/15 Safety & EMC Certifications: UL 62368-1, UL 508, TUV BS EN/EN 61558-2-16, BS EN/EN 61558-1, IEC 62368-1, EAC TP TC 004, BSMI, BIS IS13252, compliant with BS EN/EN 55032, BS EN/EN 55035, BS EN/EN 61000-6-2, BS EN/EN 61204-3 LED Indicator: Power On LED indicator Manufacturer Warranty: 3 years About the MEAN WELL HDR-30-24 The MEAN WELL HDR-30-24 is a 30 W ultra-slim DIN-rail power supply that provides a stable 24 V DC / 1.5 A output in a narrow 35 mm (2 SU) housing, ideal for compact distribution boards and space-saving control cabinets. With its wide 85–264 V AC / 120–370 V DC input range and high efficiency up to 89 %, it offers an energy-efficient 24 V control voltage source for building automation, home automation, and light industrial control systems. The adjustable 21.6–29 V output range allows precise tuning of the 24 V bus to compensate for voltage drops across wiring runs and to supply PLCs, sensors, relays, and I/O modules with reliable power. Its Class II plastic enclosure provides double insulation for enhanced user safety and simplifies installation by eliminating the need for a protective earth connection. Fanless free air convection, very low no-load power consumption below 0.3 W, a wide operating temperature range from −30 °C to +70 °C, and comprehensive protection and certification features make the HDR-30-24 a robust, long-life 24 V power solution for household and industrial automation applications.

Technical Information & Details for the MEAN WELL WDR-60-12 Power Supply Output Power: 60 W Output Voltage: 12 V DC Output Current: 5 A Input Voltage Range: 180 – 550 V AC / 254 – 780 V DC, 47 – 63 Hz Efficiency: 86.5% / 400 V AC Ripple & Noise: ≤ 120 mVp-p Inrush Current: max. 30 A @ 230 V AC / 50 A @ 400 V AC Operating Temperature: −30 °C to +85 °C Cooling: Free air convection Protection Functions: Short circuit, Overload, Over voltage, Over temperature Overvoltage Category: OVC II Isolation Voltage: 4.7 KV AC (Reinforced isolation) between input and output Dimensions (H x W x D): 125.2 mm x 32 mm x 102 mm Weight: 0.5 kg Safety & EMC Certificates: UL61010, BS EN/EN61558-2-16, AS/NZS 62368.1, EAC LED Indicator: DC OK relay contact status Manufacturer Warranty: 3 Years Information about the MEAN WELL WDR-60-12 The MEAN WELL WDR-60-12 is a robust 60W industrial DIN rail power supply characterized by its ultra-wide input range of 180 to 550V AC. This unique capability allows it to operate on either single-phase or two-phase systems, providing significant versatility for global industrial grids. Designed with a slim 32mm width, it maximizes cabinet space efficiency while maintaining high performance. The unit features reinforced isolation of 4.7KV AC, ensuring a high level of safety and reliability in sensitive industrial control and factory automation environments. Operational excellence is further supported by a wide working temperature range of -30 to +85 °C, enabling reliable performance in extreme climates. The inclusion of a DC OK relay contact provides a hardware-based signal for remote monitoring of the output status, while the adjustable output voltage (12–15V) allows users to fine-tune the power delivery to match specific application needs. With full protections against short circuits, overloads, and overvoltage, the WDR-60-12 is a dependable solution for semiconductor fabrication and telecommunication infrastructure.

Technical Information & Details about the MEAN WELL HDR-60-24 Power Supply Output Power: 60 W Output Voltage: 24 V DC Output Current: 2,5 A Current Range: 0 – 2,5 A Input Voltage Range: 85 – 264 V AC (277 V AC operational) / 120 – 370 V DC (390 V DC operational), 47 – 63 Hz Efficiency: up to 90 % Ripple & Noise: ≤ 150 mVp-p Output Voltage Adjustment Range: 21,6 – 29 V DC Voltage Tolerance: ±1,0 % Line Regulation: ±1,0 % Load Regulation: ±1,0 % Setup, Rise Time: 500 ms, 50 ms @230 V AC / 115 V AC (full load) Hold-up Time: 30 ms @230 V AC / 12 ms @115 V AC (full load) Inrush Current: 30 A @115 V AC / 60 A @230 V AC (cold start) No-load Power Consumption: < 0.3 W Operating Temperature: −30 °C to +70 °C (with derating according to curve) Cooling: fanless free air convection Protection Functions: short circuit (hiccup mode, auto recovery), overload (constant current limiting within 50–100 % of rated output voltage, auto recovery), overvoltage (shut down, re‑power to recover) Overvoltage Category: OVC III (up to 2000 m altitude) Isolation Voltage: 4000 V AC between input and output Isolation Resistance: ≥ 100 MΩ @ 500 V DC, 25 °C, 70 % RH Dimensions (W x H x D): 52,5 mm x 90 mm x 54,5 mm Weight: approx. 190 g Housing Material: insulating plastic housing, Class II, ultra slim step-shape Mounting: DIN rail TS35/7,5 or TS35/15 Safety & EMC Certifications: IEC 62368-1, UL 62368-1, UL 508, TUV BS EN/EN 61558-2-16, BS EN/EN 61558-1, EAC, BSMI, BIS IS13252, compliant with BS EN/EN 55032, BS EN/EN 55035, BS EN/EN 61000-6-2, BS EN/EN 61204-3 LED Indicator: Power On LED indicator Manufacturer Warranty: 3 years About the MEAN WELL HDR-60-24 The MEAN WELL HDR-60-24 is a 60 W ultra slim DIN-rail power supply that delivers a regulated 24 V DC / 2,5 A output in a compact 52.5 mm wide step-shape housing, ideal for space-constrained distribution boards and control cabinets. Its wide universal input range of 85–264 V AC or 120–370 V DC and high efficiency up to 90 % support energy-efficient operation in building automation, home control, and industrial control systems that rely on a stable 24 V bus. The adjustable 21,6–29 V output range allows precise tuning of the 24 V rail to compensate for voltage drops and to reliably power PLCs, sensors, relays, and I/O modules. The Class II plastic enclosure with reinforced insulation increases electrical safety and removes the need for a protective earth connection, simplifying installation and panel design. With fanless free air convection, very low no-load power consumption below 0.3 W, a wide operating temperature range from −30 °C to +70 °C, and comprehensive protection and certification features, the HDR-60-24 provides a robust, long-life 24 V power solution for demanding household and industrial automation applications.

Technical Specifications & Details for MEAN WELL MDR-20-24 Power Supply Output Power: 24 W Output Voltage: 24 V DC Output Current: 1 A Input Voltage Range: 85 – 264 V AC / 120 – 370 V DC, 47 – 63 Hz Efficiency: 84% Ripple & Noise: ≤ 150 mVp-p Inrush Current: max. 20 A @115 VAC / 40 A @230 VAC No-load Power Consumption: < 0.75 W Operating Temperature: −20 °C to +70 °C Cooling: Free air convection Protections: Short circuit, Overload (Constant current limiting), Over voltage Isolation Voltage: 3000 V AC I/P to O/P Dimensions (W x H x D): 22.5 mm x 90 mm x 100 mm Weight: approx. 170 g Safety & EMC Certificates: UL 508, TUV BS EN/EN62368-1, EAC, CB, BSMI, IS13252 LED Indicator: Power On LED indicator Manufacturer Warranty: 3 Years  Information on the MEAN WELL MDR-20-24 The MEAN WELL MDR-20-24 is a highly reliable 24W power supply designed for seamless DIN rail integration in space-constrained industrial environments. Its ultra-slim 22.5mm width allows for maximum component density on TS-35/7.5 or 15 rails, making it a preferred choice for modern control panels. A key technical advantage of this model is the built-in DC OK active signal, which provides real-time feedback on the output status to higher-level monitoring systems or PLCs. Engineered for superior energy performance, it achieves an efficiency of 84% and maintains a no-load power consumption of less than 0.75W, significantly lowering the total cost of ownership and thermal dissipation. The unit employs a constant current limiting protection strategy, ensuring it remains robust during startup surges or temporary overloads and recovers automatically once conditions stabilize. With its maintenance-free fanless design and a full suite of global safety approvals, the MDR-20-24 provides a stable 24V DC foundation for automation, telecommunications, and building management systems.
