• Output Power: 92 W
• Output Voltage: 15 V DC
• Output Current: 6.13 A
• Current Range: 0 – 6.13 A
• Input Voltage Range: 85 – 264 V AC (277 V AC operational) / 120 – 370 V DC (390 V DC operational), 47 – 63 Hz
• Efficiency: up to 89 %
• Ripple & Noise: ≤ 120 mVp-p
• Output Voltage Adjustment Range (LPS type): 15 – 17 V DC
• Extended Adjustment Range (Non‑LPS “N” type): 13.5 – 18 V DC
• Voltage Tolerance: ±2.0 %
• Line Regulation: ±1.0 %
• Load Regulation: ±1.0 %
• Setup, Rise Time: 500 ms, 60 ms @230 V AC / 115 V AC (full load)
• Hold-up Time: 30 ms @230 V AC / 12 ms @115 V AC (full load)
• AC Input Current (typ.): 3 A @115 V AC / 1.6 A @230 V AC
• Inrush Current: 35 A @115 V AC / 70 A @230 V AC (cold start)
• No-load Power Consumption: < 0.3 W
• Operating Temperature: −30 °C to +70 °C (with derating according to curve)
• Operating Humidity: 20 – 90 % RH, non‑condensing
• Storage Temperature / Humidity: −40 °C to +85 °C, 10 – 95 % RH, non‑condensing
• Cooling: fanless free air convection
• Protection Functions: short circuit (hiccup mode, auto recovery), overload (constant current limiting within 50–100 % of rated output voltage, auto recovery), overvoltage (shut down, re‑power to recover)
• Overvoltage Protection Threshold: 18.8 – 22.5 V DC
• Overvoltage Category: OVC III (up to 2000 m altitude)
• Isolation Voltage: 4000 V AC between input and output
• Isolation Resistance: ≥ 100 MΩ @ 500 V DC, 25 °C, 70 % RH
• Dimensions (W x H x D): 70 mm x 90 mm x 54.5 mm
• Weight: approx. 270 g
• Housing Material: insulating plastic, Class II, ultra slim 4‑SU step‑shape housing
• Mounting: DIN rail TS35/7.5 or TS35/15
• Vibration Resistance: 10 – 500 Hz, 2 G, 60 min (each along X, Y, Z axes)
• Safety & EMC Certifications: UL 62368‑1, UL 508, TUV BS EN/EN 61558‑2‑16, BS EN/EN 61558‑1, IEC 62368‑1, EAC TP TC 004, BSMI CNS15598‑1, BIS IS13252, compliant with BS EN/EN 55032, BS EN/EN 55035, BS EN/EN 61000‑6‑2, BS EN/EN 61204‑3
• LPS Classification: Pass LPS for “blank” models (up to 92 W, narrower adjustment range), Non‑LPS for “N” models (up to 100 W with wider adjustment range)
• LED Indicator: Power On status LED
• Manufacturer Warranty: 3 years

About the MEAN WELL HDR-100-15

The MEAN WELL HDR-100-15 is an ultra slim 100 W class DIN‑rail power supply that provides a robust 15 V DC output at up to 6.13 A in a compact 70 mm (4 SU) wide housing, making it ideal for cabinets where 15 V loads require higher current but rail space is limited. Its universal 85–264 V AC / 120–370 V DC input range, efficiency up to 89 %, and no‑load power consumption below 0.3 W make it a highly energy‑efficient 15 V bus for building automation, household control systems, and industrial control panels. The series is offered as LPS‑compliant “blank” versions with a narrower adjustment range and as “N” versions with an extended adjustment up to 18 V, giving designers flexibility between safety classification and additional voltage headroom. The Class II plastic enclosure with reinforced insulation improves electrical safety and simplifies installation by eliminating the need for a protective earth conductor. Combined with constant‑current overload protection, fanless free air convection, a wide −30 °C to +70 °C operating range, and extensive international approvals, the HDR-100-15 is a robust, low‑maintenance 15 V power solution for PLCs, I/O modules, relays, sensors, and other 15 V control electronics.
