Buffer

Not approved as an LED driver within the EU! An approved alternative is, for example, the LPF-60 series. Technical Information & Details of the MEAN WELL LPV-60-5 Power Supply Output Power: 40 W Output Voltage: 5 V DC Output Current: 8 A Input Voltage Range: 90 – 264 V AC / 127 – 370 V DC, 47 – 63 Hz Efficiency: up to 76 % Ripple & Noise: ≤ 80 mVp-p Inrush Current: max. 60 A @230 VAC No-load Power Consumption: < 0.5 W Operating Temperature: −30 °C to +70 °C Cooling: fanless natural convection Protection Features: Short-circuit, Overload, Overvoltage Overvoltage Category: OVC III Isolation Voltage: 3000 V AC between input and output Dimensions (H x W x D): 32 mm x 42.5 mm x 162.5 mm Weight: approx. 420 g Safety & EMC Certificates: CE, UL1310, TUV, CB, EAC, IP67 LED Indicator: - Manufacturer Warranty: 2 years Information about the MEAN WELL LPV-60-5 The MEAN WELL LPV-60-5 is a powerful LED power supply with 40 W and stable 5 V DC / 8 A output voltage. It excels with solid efficiency up to 76 %, fanless convection cooling for silent operation, and a fully waterproof IP67 housing. The comprehensive protection features (short-circuit, overload, and overvoltage protection) with automatic recovery ensure maximum operational safety. Perfect for LED strips, modules, outdoor lighting, and humid environments – the universal input voltage range 90–264 V AC enables worldwide deployment. With international certifications, the LPV-60-5 offers maximum flexibility, durability, and weatherproof protection in demanding environments.

Technical Information & Details for MEAN WELL HLG-240H-12A Power Supply Output Power: 192 W Output Voltage: 12 V DC (adjustable 11.2 – 12.8 V) Output Current: 16 A (adjustable 8 – 16 A) Input Voltage Range: 90 – 305 V AC / 127 – 431 V DC, 47 – 63 Hz Efficiency: 90 % Ripple & Noise: ≤ 150 mVp-p Inrush Current: max. 75 A @ 230 VAC Leakage Current: < 0.75 mA / 277 VAC Operating Temperature: −40 °C to +90 °C (case temperature) Cooling: Fanless design by free air convection Protection Functions: Short circuit, Over current (constant current limiting), Over voltage, Over temperature Ingress Protection: IP65 (Dust-tight & Water jet protected) Isolation Voltage: 3750 V AC between input and output Dimensions (L x W x H): 244.2 mm x 68 mm x 38.8 mm Weight: approx. 1300 g Safety & EMC Certificates: UL8750, EN61347-1, EN55015, EN61000-3-2 Class C Unique Feature: Voltage and current adjustable via internal potentiometer Manufacturer Warranty: 7 years Information about the MEAN WELL HLG-240H-12A The MEAN WELL HLG-240H-12A is a flagship LED driver designed for professional lighting applications where maximum performance and flexibility are required. This model features a sophisticated dual-mode output, enabling it to operate in both Constant Voltage (CV) and Constant Current (CC) modes to suit various LED array configurations. The "A" version is specifically engineered with built-in potentiometers, allowing installers to manually fine-tune the output voltage and current levels to meet specific project needs or dimming requirements. Its rugged metal housing and IP65 ingress protection make it highly resistant to environmental factors, while the fanless thermal design allows for reliable, silent operation even in harsh conditions with case temperatures up to +90 °C. With a typical life expectancy of over 62,000 hours and a comprehensive 7-year manufacturer warranty, the HLG-240H-12A is a long-term solution for high-bay lighting, outdoor street lamps, and architectural installations that demand superior quality and minimal maintenance.

Not approved as an LED driver within the EU! An approved alternative is, for example, the LPF-60 series. Technical Information & Details of the MEAN WELL LPV-60-12 Power Supply Output Power: 60 W Output Voltage: 12 V DC Output Current: 5 A Input Voltage Range: 90 – 264 V AC / 127 – 370 V DC, 47 – 63 Hz Efficiency: up to 83 % Ripple & Noise: ≤ 120 mVp-p Inrush Current: max. 60 A @230 VAC No-load Power Consumption: < 0.5 W Operating Temperature: −30 °C to +70 °C Cooling: fanless natural convection Protection Features: Short-circuit, Overload, Overvoltage Overvoltage Category: OVC III Isolation Voltage: 3000 V AC between input and output Dimensions (H x W x D): 32 mm x 42.5 mm x 162.5 mm Weight: approx. 420 g Safety & EMC Certificates: CE, UL1310, TUV, CB, EAC, IP67 LED Indicator: - Manufacturer Warranty: 2 years Information about the MEAN WELL LPV-60-12 The MEAN WELL LPV-60-12 is a powerful LED power supply with 60 W and stable 12 V DC / 5 A output voltage. It excels with excellent efficiency up to 83 %, fanless convection cooling for silent operation, and a fully waterproof IP67 housing. The comprehensive protection features (short-circuit, overload, and overvoltage protection) with automatic recovery ensure maximum operational safety. Perfect for LED strips, modules, outdoor lighting, and humid environments – the universal input voltage range 90–264 V AC enables worldwide deployment. With international certifications, the LPV-60-12 offers maximum flexibility, durability, and weatherproof protection in demanding environments.

Not approved as an LED driver within the EU! An approved alternative is, for example, the LPF-25 series. Technical Information & Details of the MEAN WELL LPV-20-24 Power Supply Output Power: 20 W Output Voltage: 24 V DC Output Current: 0.84 A Input Voltage Range: 90 – 264 V AC / 127 – 370 V DC, 47 – 63 Hz Efficiency: up to 83 % Ripple & Noise: ≤ 150 mVp-p Inrush Current: max. 25 A @230 VAC No-load Power Consumption: < 0.5 W Operating Temperature: −30 °C to +70 °C Cooling: fanless natural convection Protection Features: Short-circuit, Overload, Overvoltage Overvoltage Category: OVC III Isolation Voltage: 3000 V AC between input and output Dimensions (H x W x D): 26 mm x 35 mm x 118 mm Weight: approx. 190 g Safety & EMC Certificates: CE, UL8750, TUV, CB, EAC, IP67 LED Indicator: - Manufacturer Warranty: 2 years Information about the MEAN WELL LPV-20-24 The MEAN WELL LPV-20-24 is a compact LED power supply with 20 W and stable 24 V DC / 0.84 A output voltage. It excels with excellent efficiency up to 83 %, fanless convection cooling for silent operation, and a fully waterproof IP67 housing. The comprehensive protection features (short-circuit, overload, and overvoltage protection) with automatic recovery ensure maximum operational safety. Perfect for LED lighting, decorative applications, outdoor use, and humid environments – the universal input voltage range 90–264 V AC enables worldwide deployment. With international certifications, the LPV-20-24 offers maximum flexibility, durability, and weatherproof protection in demanding environments.

Technische Eigenschaften des MEAN WELL PLN-100-24 Leistung: 96W Universeller AC Eingang/ Breiter Eingangsbereich von 90 bis 264VAC Schutz vor Kurzschluss/ Überstrom/ Überspannung/ Überhitzung Kühlung durch freie Luftkonvektion Eingebaute Konstantstrombegrenzungsschaltung mit einstellbarem OCP Level Vollständig isoliertes Plastikgehäuse Integrierte, aktive PFC-Funktion IP64 Design für Indoor und Outdoor Installationen Schmale und kompakte Größe Class II Schaltnetzteil/ kein FG 100% Volllast burn-in Test Hohe Zuverlässigkeit, niedrige Kosten: bestes Preis-Leistungsverhältnis Geeignet für feuchte/ nasse Umgebung Geeignet für LED Beleuchtungen und LED Displays 2 Jahre Garantie

Technical Information & Details for MEAN WELL HLG-240H-24A Power Supply Output Power: 240 W Output Voltage: 24 V DC Voltage Adj. Range: 22.4 V – 25.6 V (via built-in potentiometer) Rated Current: 10 A Current Adj. Range: 5 A – 10 A (via built-in potentiometer) Input Voltage Range: 90 – 305 V AC / 127 – 431 V DC Efficiency: 93 % (typ.) Ripple & Noise: max. 150 mVp-p Operating Temperature: −40 °C to +90 °C (case temperature) Ingress Protection: IP65 (Dust-tight & Water jet protected) Typical Lifetime: > 62,000 hours Dimensions (L x W x H): 244.2 mm x 68 mm x 38.8 mm Manufacturer Warranty: 7 years Information about the MEAN WELL HLG-240H-24A The MEAN WELL HLG-240H-24A is a high-performance 240W AC/DC LED driver renowned for its dual-mode constant voltage and constant current output strategy. This A-type model is specifically engineered for flexibility, featuring internal potentiometers that allow for the manual fine-tuning of output voltage and current levels to perfectly suit the requirements of connected LED systems. Encased in a ruggedized metal housing with an IP65 rating, it is highly durable for both indoor and outdoor applications such as LED street lighting, parking space illumination, and greenhouse lighting. The unit achieves a superior efficiency of 93 % and utilizes a fanless thermal design, ensuring silent and reliable operation under free air convection at temperatures up to +90 °C. Furthermore, its Type HL certification qualifies it for use in Class I, Division 2 hazardous locations. Backed by an industry-leading 7-year manufacturer warranty and a service life expectancy of more than 62,000 hours, the HLG-240H-24A provides a robust and maintenance-free power solution for large-scale architectural and high-bay industrial projects.

Not approved as an LED driver within the EU! An approved alternative is, for example, the LPF-25 series. Technical Information & Details of the MEAN WELL LPV-20-12 Power Supply Output Power: 20 W Output Voltage: 12 V DC Output Current: 1.67 A Input Voltage Range: 90 – 264 V AC / 127 – 370 V DC, 47 – 63 Hz Efficiency: up to 81 % Ripple & Noise: ≤ 120 mVp-p Inrush Current: max. 25 A @230 VAC No-load Power Consumption: < 0.5 W Operating Temperature: −30 °C to +70 °C Cooling: fanless natural convection Protection Features: Short-circuit, Overload, Overvoltage Overvoltage Category: OVC III Isolation Voltage: 3000 V AC between input and output Dimensions (H x W x D): 26 mm x 35 mm x 118 mm Weight: approx. 190 g Safety & EMC Certificates: CE, UL8750, TUV, CB, EAC, IP67 LED Indicator: - Manufacturer Warranty: 2 years Information about the MEAN WELL LPV-20-12 The MEAN WELL LPV-20-12 is a compact LED power supply with 20 W and stable 12 V DC / 1.67 A output voltage. It excels with excellent efficiency up to 81 %, fanless convection cooling for silent operation, and a fully waterproof IP67 housing. The comprehensive protection features (short-circuit, overload, and overvoltage protection) with automatic recovery ensure maximum operational safety. Perfect for LED lighting, decorative applications, outdoor use, and humid environments – the universal input voltage range 90–264 V AC enables worldwide deployment. With international certifications, the LPV-20-12 offers maximum flexibility, durability, and weatherproof protection in demanding environments.

Not approved as an LED driver within the EU! An approved alternative is, for example, the LPF-60 series. Technical Information & Details of the MEAN WELL LPV-60-24 Power Supply Output Power: 60 W Output Voltage: 24 V DC Output Current: 2.5 A Input Voltage Range: 90 – 264 V AC / 127 – 370 V DC, 47 – 63 Hz Efficiency: up to 86 % Ripple & Noise: ≤ 150 mVp-p Inrush Current: max. 60 A @230 VAC No-load Power Consumption: < 0.5 W Operating Temperature: −30 °C to +70 °C Cooling: fanless natural convection Protection Features: Short-circuit, Overload, Overvoltage Overvoltage Category: OVC III Isolation Voltage: 3000 V AC between input and output Dimensions (H x W x D): 32 mm x 42.5 mm x 162.5 mm Weight: approx. 420 g Safety & EMC Certificates: CE, UL1310, TUV, CB, EAC, IP67 LED Indicator: - Manufacturer Warranty: 2 years Information about the MEAN WELL LPV-60-24 The MEAN WELL LPV-60-24 is a powerful LED power supply with 60 W and stable 24 V DC / 2.5 A output voltage. It excels with excellent efficiency up to 86 %, fanless convection cooling for silent operation, and a fully waterproof IP67 housing. The comprehensive protection features (short-circuit, overload, and overvoltage protection) with automatic recovery ensure maximum operational safety. Perfect for LED strips, modules, outdoor lighting, and humid environments – the universal input voltage range 90–264 V AC enables worldwide deployment. With international certifications, the LPV-60-24 offers maximum flexibility, durability, and weatherproof protection in demanding environments.

Not approved as an LED driver within the EU! An approved alternative is, for example, the LPF-25 series. Technical Information & Details of the MEAN WELL LPV-35-24 Power Supply Output Power: 36 W Output Voltage: 24 V DC Output Current: 1.5 A Input Voltage Range: 90 – 264 V AC / 127 – 370 V DC, 47 – 63 Hz Efficiency: up to 85 % Ripple & Noise: ≤ 150 mVp-p Inrush Current: max. 55 A @230 VAC No-load Power Consumption: < 0.5 W Operating Temperature: −30 °C to +75 °C Cooling: fanless natural convection Protection Features: Short-circuit, Overload, Overvoltage Overvoltage Category: OVC III Isolation Voltage: 3000 V AC between input and output Dimensions (H x W x D): 30 mm x 40 mm x 148 mm Weight: approx. 340 g Safety & EMC Certificates: CE, UL1310, TUV, CB, EAC, IP67 LED Indicator: - Manufacturer Warranty: 2 years Information about the MEAN WELL LPV-35-24 The MEAN WELL LPV-35-24 is a compact LED power supply with 36 W and stable 24 V DC / 1.5 A output voltage. It excels with excellent efficiency up to 85 %, fanless convection cooling for silent operation, and a fully waterproof IP67 housing. The comprehensive protection features (short-circuit, overload, and overvoltage protection) with automatic recovery ensure maximum operational safety. Perfect for LED strips, camera systems, decorative applications, and humid environments – the universal input voltage range 90–264 V AC enables worldwide deployment. With international certifications, the LPV-35-24 offers maximum flexibility, durability, and weatherproof protection in demanding environments.

Not approved as an LED driver within the EU! An approved alternative is, for example, the LPF-25 series. Technical Information & Details of the MEAN WELL LPV-35-12 Power Supply Output Power: 36 W Output Voltage: 12 V DC Output Current: 3 A Input Voltage Range: 90 – 264 V AC / 127 – 370 V DC, 47 – 63 Hz Efficiency: up to 84 % Ripple & Noise: ≤ 120 mVp-p Inrush Current: max. 55 A @230 VAC No-load Power Consumption: < 0.5 W Operating Temperature: −30 °C to +75 °C Cooling: fanless natural convection Protection Features: Short-circuit, Overload, Overvoltage Overvoltage Category: OVC III Isolation Voltage: 3000 V AC between input and output Dimensions (H x W x D): 30 mm x 40 mm x 148 mm Weight: approx. 340 g Safety & EMC Certificates: CE, UL1310, TUV, CB, EAC, IP67 LED Indicator: - Manufacturer Warranty: 2 years Information about the MEAN WELL LPV-35-12 The MEAN WELL LPV-35-12 is a compact LED power supply with 36 W and stable 12 V DC / 3 A output voltage. It excels with excellent efficiency up to 84 %, fanless convection cooling for silent operation, and a fully waterproof IP67 housing. The comprehensive protection features (short-circuit, overload, and overvoltage protection) with automatic recovery ensure maximum operational safety. Perfect for LED strips, camera systems, decorative applications, and humid environments – the universal input voltage range 90–264 V AC enables worldwide deployment. With international certifications, the LPV-35-12 offers maximum flexibility, durability, and weatherproof protection in demanding environments.
