Technical Information & Details for the MEAN WELL LRS-150-12 Power Supply Output Power: 150 W Output Voltage: 12 V DC Output Current: 12.5 A Input Voltage Range: 85 – 132 VAC / 170 – 264 VAC (selectable by switch), 240 – 370 VDC Efficiency: up to 87.5 % Ripple & Noise: ≤ 150 mVp-p Inrush Current: 60 A / 230 VAC (Cold Start) No-Load Power Consumption: < 0.5 W Operating Temperature: −30 °C to +70 °C Cooling: Free air convection (fanless) Protection Functions: Short circuit, Overload, Over voltage, Over temperature Over Voltage Category: OVC III Isolation Voltage: 4000 V AC between Input and Output Dimensions (L x W x H): 159 mm x 97 mm x 30 mm Weight: 0.42 Kg Safety & EMC Certificates: UL62368-1, TUV, CB, CE, EAC, BSMI, CCC LED Indicator: Power On Indicator Manufacturer Warranty: 3 Years Information about the MEAN WELL LRS-150-12 The MEAN WELL LRS-150-12 is a highly efficient, 150W single-output enclosed type power supply characterized by its ultra-compact 1U low profile design of only 30mm. This model is engineered with a metallic mesh case that significantly enhances heat dissipation, allowing the unit to operate reliably under free air convection without the need for an external fan. One of its most impressive technical strengths is the ability to withstand 300VAC surge inputs for up to 5 seconds and 5G anti-vibration capability, making it exceptionally durable for rigorous industrial environments where mechanical stability and electrical resilience are paramount. Beyond its physical robustness, the LRS-150-12 is designed for global energy efficiency compliance, featuring an extremely low no-load power consumption of less than 0.5W. This ensures that end systems can easily meet international eco-design requirements. The unit is safety-rated under Over Voltage Category III (OVC III), providing an extra layer of protection for fixed installation parts and industrial control systems. With its high efficiency of 87.5% and wide operating temperature range from -30°C to +70°C, it serves as a high-performance solution for industrial automation machinery, household appliances, and diverse electronic instruments requiring a stable 12V DC source.
