GST60A48-P1J

Cold appliance plug cable / connection cable IEC 60320 C14 (C13) Euro L angled 1.8m

Technical Information & Details about the MEAN WELL HDR-100-24N Power Supply Output Power: 100.8 W Output Voltage: 24 V DC (nominal) Output Current: 4.2 A Current Range: 0 – 4.2 A Input Voltage Range: 85 – 264 V AC (277 V AC operational) / 120 – 370 V DC (390 V DC operational), 47 – 63 Hz Efficiency: typ. 90 % Ripple & Noise: ≤ 150 mVp-p Output Voltage Adjustment Range: 21.6 – 29 V DC (extended Non‑LPS range) Voltage Tolerance: ±2.0 % Line Regulation: ±1.0 % Load Regulation: ±1.0 % Setup, Rise Time: 500 ms, 60 ms @230 V AC / 115 V AC (full load) Hold-up Time: 30 ms @230 V AC / 12 ms @115 V AC (full load) AC Input Current (typ.): 3 A @115 V AC / 1.6 A @230 V AC Inrush Current: 35 A @115 V AC / 70 A @230 V AC (cold start) No-load Power Consumption: < 0.3 W Operating Temperature: −30 °C to +70 °C (with derating according to curve) Operating Humidity: 20 – 90 % RH, non‑condensing Storage Conditions: −40 °C to +85 °C, 10 – 95 % RH, non‑condensing Cooling: fanless free air convection Protection Features: short circuit (hiccup mode, auto recovery), overload (constant current limiting within 50–100 % of rated output voltage, auto recovery), overvoltage (shut down, re‑power to recover) Overvoltage Protection Threshold: 30 – 36 V DC Overvoltage Category: OVC III (up to 2000 m altitude) Isolation Voltage: 4000 V AC between input and output Isolation Resistance: ≥ 100 MΩ @ 500 V DC, 25 °C, 70 % RH Dimensions (W x H x D): 70 mm x 90 mm x 54.5 mm Weight: approx. 270 g Housing Material: insulating plastic housing, Class II, ultra‑slim 4‑SU step‑shape Mounting: DIN rail TS35/7.5 or TS35/15 Vibration Resistance: 10 – 500 Hz, 2 G, 60 min per axis (X, Y, Z) Safety & EMC Certificates: UL 62368‑1, UL 508, TUV BS EN/EN 61558‑2‑16, BS EN/EN 61558‑1, IEC 62368‑1, EAC TP TC 004, BSMI CNS15598‑1, BIS IS13252, compliant with BS EN/EN 55032, BS EN/EN 55035, BS EN/EN 61000‑6‑2, BS EN/EN 61204‑3 LPS Classification: Non‑LPS (extended adjustment range, higher usable output power up to 100.8 W) LED Indicator: Power‑On status LED Manufacturer Warranty: 3 years About the MEAN WELL HDR-100-24N The MEAN WELL HDR-100-24N is the Non‑LPS version of the HDR‑100‑24 models and delivers up to 100.8 W at 24 V DC and 4.2 A in an ultra‑slim 70 mm DIN‑rail housing. Its extended 21.6–29 V adjustment range offers additional voltage headroom for long cable runs, inductive loads and demanding 24 V control circuits, going well beyond the tighter LPS‑compliant window of “blank” units. Combined with universal input, high efficiency, fanless free air convection, comprehensive protection features and broad safety/EMC approvals, HDR-100-24N is a powerful, flexible 24 V supply for industrial control systems, building automation, valves, relays, sensors and OEM applications that must fully utilize the 100 W class.
