IRM-02-24S

Product information "IRM-02-24S"

Technical Information & Details for MEAN WELL IRM-02-24S Power Supply

  • Output Power: 2.0 W
  • Output Voltage: 24 V DC
  • Output Current: 0.083 A (83 mA)
  • Mounting Type / Package: SMD Style (Surface Mount Device)
  • Input Voltage Range: 85 – 305 V AC / 120 – 430 V DC, 47 – 63 Hz
  • Efficiency: 74%
  • Ripple & Noise: ≤ 200 mVp-p
  • Inrush Current: max. 5 A @ 115 VAC / 10 A @ 230 VAC
  • No-Load Power Consumption: < 0.075 W
  • Operating Temperature: −30 °C to +85 °C
  • Cooling: Free air convection
  • Protections: Short circuit, Overload, Over voltage
  • Overvoltage Category: OVC II
  • Isolation Voltage: 4200 V AC (4.2 kV AC) input to output
  • Dimensions (L x W x H): 33.7 mm x 22.2 mm x 16 mm
  • Weight: approx. 24 g
  • Safety & EMC Standards: IEC62368-1, IEC61558-1/-2-16, UL62368-1, TUV BS EN/EN62368-1, EAC, CE, CB
  • Vibration Resistance: 5G (10–500 Hz)
  • Warranty: 3 Years

Information about MEAN WELL IRM-02-24S

Delivering standard 24 V DC industrial voltage in an SMT-compatible footprint, this 2-watt surface-mount AC/DC module streamlines board layout by eliminating external power components. Fully potted in silicone compound, the ruggedized housing provides certified vibration resistance up to 5G as well as complete protection from ambient moisture and dust. It maintains stable, convection-cooled operation across an expansive operating temperature range of −30 °C to +85 °C in demanding field environments. Reinforced by a high dielectric isolation voltage of 4.2 kV AC and adherence to rigorous OVC II safety standards, this miniature converter offers excellent longevity for embedded systems, IoT sensors, and factory automation devices.


Verfügbare Downloads
Download IRM-02 Datenblatt
Eigenschaften für "IRM-02-24S"
Approval: CB, CE, TÜV
Efficiency: 77%
Height: 22,2
Length: 33,7
Rated current: 0,083
Series: IRM
Voltage: 24 VDC
Warranty: 3 years
Wattage: 2 W
Weight: 0,024kg
Width: 15
