IRM-02-3,3S

Product information "IRM-02-3,3S"

Technical Information & Details for MEAN WELL IRM-02-3.3S Power Supply

  • Output Power: 1.98 W
  • Output Voltage: 3.3 V DC
  • Output Current: 0.6 A (600 mA)
  • Mounting Type / Package: SMD Style (Surface Mount Device)
  • Input Voltage Range: 85 – 305 V AC / 120 – 430 V DC, 47 – 63 Hz
  • Efficiency: 66%
  • Ripple & Noise: ≤ 150 mVp-p
  • Inrush Current: max. 5 A @ 115 VAC / 10 A @ 230 VAC
  • No-Load Power Consumption: < 0.075 W
  • Operating Temperature: −30 °C to +85 °C
  • Cooling: Free air convection
  • Protections: Short circuit, Overload, Over voltage
  • Overvoltage Category: OVC II
  • Isolation Voltage: 4200 V AC (4.2 kV AC) input to output
  • Dimensions (L x W x H): 33.7 mm x 22.2 mm x 16 mm
  • Weight: approx. 24 g
  • Safety & EMC Standards: IEC62368-1, IEC61558-1/-2-16, UL62368-1, TUV BS EN/EN62368-1, EAC, CE, CB
  • Vibration Resistance: 5G (10–500 Hz)
  • Warranty: 3 Years

Information about MEAN WELL IRM-02-3.3S

Designed specifically for automated surface-mount assembly, this SMD-style AC/DC converter delivers a stable 3.3 V DC rail for low-power electronic systems directly on board. Encapsulated in a heat-dissipating phenolic case with silicone potting, the robust design achieves certified vibration resistance up to 5G while shielding sensitive components against dust and moisture. The unit effortlessly withstands extreme ambient temperatures across a wide operating temperature range of −30 °C to +85 °C without needing forced cooling fans. Featuring high dielectric protection through an isolation voltage of 4.2 kV AC and full alignment with OVC II safety ratings, this power module represents a highly reliable option for smart sensors, IoT nodes, and compact automation hardware.


Verfügbare Downloads
Download IRM-02 Datenblatt
Eigenschaften für "IRM-02-3,3S"
Approval: CB, CE, TÜV
Efficiency: 66 %
Height: 22,2
Length: 33,7
Rated current: 0,6
Series: IRM
Voltage: 3,3 VDC
Warranty: 3 years
Wattage: 2 W
Weight: 0,024kg
Width: 15
