Technical Information & Details for MEAN WELL IRM-02-3.3 Power Supply
- Output Power: 1.98 W
- Output Voltage: 3.3 V DC
- Output Current: 0.6 A (600 mA)
- Input Voltage Range: 85 – 305 V AC / 120 – 430 V DC, 47 – 63 Hz
- Efficiency: 66%
- Ripple & Noise: ≤ 150 mVp-p
- Inrush Current: max. 5 A @ 115 VAC / 10 A @ 230 VAC
- No-Load Power Consumption: < 0.075 W
- Operating Temperature: −30 °C to +85 °C
- Cooling: Free air convection
- Protections: Short circuit, Overload, Over voltage
- Overvoltage Category: OVC II
- Isolation Voltage: 4200 V AC (4.2 kV AC) input to output
- Dimensions (L x W x H): 33.7 mm x 22.2 mm x 15 mm
- Weight: approx. 24 g
- Safety & EMC Standards: IEC62368-1, IEC61558-1/-2-16, UL62368-1, TUV BS EN/EN62368-1, EAC, CE, CB
- Vibration Resistance: 5G (10–500 Hz)
- Warranty: 3 Years
Information about MEAN WELL IRM-02-3.3
Engineered for direct PCB mounting, this miniature 2-watt AC/DC power module converts universal input voltages safely down to a stable 3.3 V DC rail for sensitive electronics. Encapsulated in a phenolic case with fully potted silicone, it features exceptional vibration resistance up to 5G alongside high protection against dust and moisture. Its robust internal design ensures safe operation across an extreme operating temperature range of −30 °C to +85 °C without requiring forced cooling. Backed by a high isolation voltage of 4.2 kV AC and full compliance with OVC II safety standards, this ultra-small module provides superior reliability for industrial automation, IoT nodes, and handheld electronic devices.
