Technical Specifications & Details for MEAN WELL IRM-01-3.3 Power Supply
- Output Wattage: 1 W
- Output Voltage: 3.3 V DC
- Output Current: 300 mA
- Input Voltage Range: 85 – 305 V AC / 120 – 430 V DC, 47 – 63 Hz
- Efficiency: 66%
- Ripple & Noise: ≤ 150 mVp-p
- Inrush Current: max. 5 A @115 VAC / 10 A @230 VAC
- No-Load Power Consumption: < 0.075 W
- Operating Temperature: −30 °C to +85 °C
- Cooling: Free air convection
- Protections: Short circuit, Overload, Over voltage
- Overvoltage Category: OVC II
- Isolation Voltage: 4200 V AC between Input and Output
- Dimensions (L x W x H): 33.7 mm x 22.2 mm x 15 mm
- Weight: approx. 24 g
- Safety & EMC Standards: IEC62368-1, IEC61558-1/-2-16, UL62368-1, TUV BS EN/EN62368-1, EAC, BSMI
- LED Indicator: None
- Manufacturer Warranty: 3 Years
Information about MEAN WELL IRM-01-3.3
Designed for direct PCB soldering in miniaturized electronics, the MEAN WELL IRM-01-3.3 AC/DC module generates a low-ripple 3.3 V DC output to drive low-voltage processors and sensor networks. Featuring an ultra-low standby power draw under 0.075 W, it ensures high energy conservation while offering maximum shock durability through encapsulated 5G vibration resistance. The unit provides supreme safety margins with a heavy-duty 4200 V AC isolation voltage, shielding downstream components against high-voltage spikes. Furthermore, its internal filter topology allows full compliance with BS EN/EN55032 Class B EMI standards without requiring additional board space for discrete components, operating flawlessly across an extended operating temperature range of −30 °C to +85 °C.
