Technical Information & Details for MEAN WELL EPS-65-15 Power Supply Output Power: 65.1 W (Peak load 72 W for 10 sec.) Output Voltage: 15 V DC Output Current: 4.34 A (Current range 0 – 4.34 A / up to 4.8 A per spec table) Input Voltage Range: 90 – 264 V AC / 127 – 370 V DC (DC input operation possible by connecting AC/N(+), AC/L(-)) Efficiency: 87% Ripple & Noise: ≤ 150 mVp-p Inrush Current: Cold start 60 A @230 VAC No-Load Power Consumption: < 0.3 W Operating Temperature: −30 °C to +70 °C (Refer to output load derating curve) Cooling: Fanless free air convection Protections: Short circuit, Overload, Over voltage Voltage Adj. Range: 13.5 – 16.5 V DC Isolation Voltage: I/P-O/P: 3 kVAC, I/P-FG: 2 kVAC, O/P-FG: 0.5 kVAC Dimensions (L x W x H): PCB: 101.6 mm x 50.8 mm x 29 mm; with optional Case (-C): 103.4 mm x 62 mm x 37 mm Weight: PCB: 0.15 kg; with optional Case: 0.3 kg Safety & EMC Certificates: UL62368-1, TUV BS EN/EN62368-1, CCC GB4943.1, EAC TP TC 004 Form Factor: PCB type open frame (standard) or optional enclosed type (-C) / L-bracket Manufacturer Warranty: 3 Years Information about MEAN WELL EPS-65-15 The MEAN WELL EPS-65-15 is a compact 65W industrial switching power supply featuring a 4" x 2" footprint, available as a standard PCB-type open frame or with an optional enclosed cover (-C) and L-bracket. Designed to meet strict energy standards, it accepts a universal AC input range and maintains a low no-load power consumption of under 0.3 W. Key features include reliable fanless free air convection cooling across a wide operational temperature range of −30 °C to +70 °C, an onboard LED power indicator, and a voltage adjustment trimmer ranging from 13.5 to 16.5 V DC. Built-in protections against short circuits, overloads (hiccup mode), and overvoltage ensure maximum reliability for industrial equipment, factory automation, and mechanical applications.

Technical Information & Details for MEAN WELL EPS-65-24 Power Supply Output Power: 65.04 W (Peak load 72 W for 10 sec.) Output Voltage: 24 V DC Output Current: 2.71 A (Current range 0 – 2.71 A / up to 3 A per spec table) Input Voltage Range: 90 – 264 V AC / 127 – 370 V DC (DC input operation possible by connecting AC/N(+), AC/L(-)) Efficiency: 88% Ripple & Noise: ≤ 240 mVp-p Inrush Current: Cold start 60 A @230 VAC No-Load Power Consumption: < 0.3 W Operating Temperature: −30 °C to +70 °C (Refer to output load derating curve) Cooling: Fanless free air convection Protections: Short circuit, Overload, Over voltage Voltage Adj. Range: 21.6 – 27 V DC Isolation Voltage: I/P-O/P: 3 kVAC, I/P-FG: 2 kVAC, O/P-FG: 0.5 kVAC Dimensions (L x W x H): PCB: 101.6 mm x 50.8 mm x 29 mm; with optional Case (-C): 103.4 mm x 62 mm x 37 mm Weight: PCB: 0.15 kg; with optional Case: 0.3 kg Safety & EMC Certificates: UL62368-1, TUV BS EN/EN62368-1, CCC GB4943.1, EAC TP TC 004 Form Factor: PCB type open frame (standard) or optional enclosed type (-C) / L-bracket Manufacturer Warranty: 3 Years Information about MEAN WELL EPS-65-24 The MEAN WELL EPS-65-24 is a compact 65W industrial switching power supply featuring a 4" x 2" footprint, available as a standard PCB-type open frame or with an optional enclosed cover (-C) and L-bracket. Designed to meet strict energy standards, it accepts a universal AC input range and maintains a low no-load power consumption of under 0.3 W. Key features include reliable fanless free air convection cooling across a wide operational temperature range of −30 °C to +70 °C, an onboard LED power indicator, and a voltage adjustment trimmer ranging from 21.6 to 27 V DC. Built-in protections against short circuits, overloads (hiccup mode), and overvoltage ensure maximum reliability for industrial equipment, factory automation, and mechanical applications.

Technical Information & Details for MEAN WELL EPS-65-12 Power Supply Output Power: 65.04 W (Peak load 72 W for 10 sec.) Output Voltage: 12 V DC Output Current: 5.43 A (Current range 0 – 5.43 A / up to 6 A per spec table) Input Voltage Range: 90 – 264 V AC / 127 – 370 V DC (DC input operation possible by connecting AC/N(+), AC/L(-)) Efficiency: 86% Ripple & Noise: ≤ 120 mVp-p Inrush Current: Cold start 60 A @230 VAC No-Load Power Consumption: < 0.3 W Operating Temperature: −30 °C to +70 °C (Refer to output load derating curve) Cooling: Fanless free air convection Protections: Short circuit, Overload, Over voltage Voltage Adj. Range: 10.8 – 13.5 V DC Isolation Voltage: I/P-O/P: 3 kVAC, I/P-FG: 2 kVAC, O/P-FG: 0.5 kVAC Dimensions (L x W x H): PCB: 101.6 mm x 50.8 mm x 29 mm; with optional Case (-C): 103.4 mm x 62 mm x 37 mm Weight: PCB: 0.15 kg; with optional Case: 0.3 kg Safety & EMC Certificates: UL62368-1, TUV BS EN/EN62368-1, CCC GB4943.1, EAC TP TC 004 Form Factor: PCB type open frame (standard) or optional enclosed type (-C) / L-bracket Manufacturer Warranty: 3 Years Information about MEAN WELL EPS-65-12 The MEAN WELL EPS-65-12 is a compact 65W industrial switching power supply featuring a 4" x 2" footprint, available as a standard PCB-type open frame or with an optional enclosed cover (-C) and L-bracket. Designed to meet strict energy standards, it accepts a universal AC input range and maintains a low no-load power consumption of under 0.3 W. Key features include reliable fanless free air convection cooling across a wide operational temperature range of −30 °C to +70 °C, an onboard LED power indicator, and a voltage adjustment trimmer ranging from 10.8 to 13.5 V DC. Built-in protections against short circuits, overloads (hiccup mode), and overvoltage ensure maximum reliability for industrial equipment, factory automation, and mechanical applications.
