• Output Power: 45 W (49.5 W Peak for 10 sec.)
• Output Voltage: 15 V DC
• Output Current: 3 A (Peak 3.3 A)
• Input Voltage Range: 80 – 264 V AC / 113 – 370 V DC, 47 – 63 Hz
• Efficiency: up to 92.5%
• Ripple & Noise: ≤ 120 mVp-p
• Inrush Current: max. 30 A @115 VAC / 60 A @230 VAC
• No-load Power Consumption: < 0.1 W
• Operating Temperature: −30 °C to +80 °C
• Cooling: Free air convection
• Protection Functions: Short circuit, Overload, Over voltage, Over temperature
• Overvoltage Category: OVC II
• Isolation Voltage: 4000 V AC (2xMOPP)
• Dimensions (L x W x H): 109 mm x 52 mm x 33.5 mm (Screw Terminal Type)
• Weight: approx. 206 g
• Safety & EMC Certificates: IEC/EN60601-1, ANSI/AAMI ES60601-1, CE, EAC
• Special Feature: Medical Safety Approved & Screw Terminal Style
• Manufacturer Warranty: 3 Years

Product Information for MEAN WELL MPM-45-15ST

The MEAN WELL MPM-45-15ST is a premium 45W medical-grade AC/DC power module featuring a high-density screw terminal chassis mount design. According to the MPM-45-spec.pdf, this power supply is fully compliant with IEC/EN60601-1 and ANSI/AAMI ES60601-1 safety regulations, incorporating 2xMOPP isolation to ensure maximum patient safety. Its defining characteristic is the ultra-low leakage current (less than 100 µA), which makes it an ideal solution for BF-rated medical devices that require direct patient contact. The "ST" version provides integrated terminal blocks and mounting holes, facilitating easy installation into various medical equipment enclosures without the need for custom PCB layouts.

Engineered for excellence, the MPM-45-15ST boasts an impressive efficiency of 92.5% and maintains a no-load power consumption of under 0.1W, adhering to global green energy standards. It is built to endure demanding environments, operating reliably between -30 °C and +80 °C and resisting vibrations up to 5G. With a peak power capability of 49.5W and robust protections against short circuits, overloads, and over-voltage, this 15V unit provides a secure power foundation for mobile medical workstations, diagnostic monitors, and portable examination instruments. Its combination of compact size and high safety makes it a benchmark for high-reliability medical power conversion.
