PM-15-12 Auslaufmodell

Technical Information & Details for MEAN WELL MPM-15-12 Power Supply Output Power: 15 W (16.6 W Peak for 10s) Output Voltage: 12 V DC Output Current: 1.25 A Input Voltage Range: 80 – 264 V AC / 113 – 370 V DC, 47 – 440 Hz Efficiency: 85.5 % Ripple & Noise: ≤ 150 mVp-p Inrush Current: max. 20 A @115 VAC / 45 A @230 VAC No-load Power Consumption: < 0.1 W Operating Temperature: −40 °C to +85 °C Cooling: Free air convection Protection Functions: Short circuit, Overload, Over voltage, Over temperature Isolation Level: 2xMOPP (Primary-Secondary) Isolation Voltage: 4000 V AC Dimensions (H x W x D): 24 mm x 52.4 mm x 27.2 mm Weight: approx. 56 g Safety & EMC Certificates: ANSI/AAMI ES60601-1, IEC/EN60601-1, EN60335-1, CE, EAC Design Standard: Class II (no FG) double insulation Manufacturer Warranty: 3 Years Information about the MEAN WELL MPM-15-12 The MEAN WELL MPM-15-12 is a high-density, 15W medical grade AC/DC module engineered for PCB mounting in demanding clinical environments. As specified in the MPM-15-spec.pdf, this unit features 2xMOPP (Means of Patient Protection) safety levels and an ultra-low touch current of less than 80 µA, making it exceptionally safe for BF-rated medical equipment. Its fully encapsulated plastic case provides high-level protection against environmental contaminants and 2G anti-vibration capabilities, ensuring stable 12V performance for portable medical monitors and laboratory instruments. Beyond safety, this power supply is a leader in energy conservation, boasting high efficiency up to 85.5% and a no-load power consumption of less than 0.1W, categorizing it as a "Green Medical" power solution. It operates efficiently without a fan, utilizing natural convection to maintain stability across a broad temperature range from -40°C to +85°C. Equipped with automated recovery protections for short circuits and thermal overloads, the MPM-15-12 represents a highly reliable and compact choice for modern healthcare electronics, supported by a 3-year manufacturer warranty.
