PM-05-5 End of Life

Technical Information & Details for MEAN WELL MPM-05-5 Power Supply Output Power: 5 W Output Voltage: 5 V DC Output Current: 1 A Input Voltage Range: 80 – 264 V AC / 113 – 370 V DC, 47 – 440 Hz Efficiency: 80% Ripple & Noise: ≤ 100 mVp-p Inrush Current: max. 25 A @115 VAC / 45 A @230 VAC No-load Power Consumption: < 0.075 W Operating Temperature: −40 °C to +85 °C Cooling: Free air convection Protection Functions: Short circuit, Overload, Over voltage, Over temperature Isolation Voltage: 4000 V AC (Input to Output) Leakage Current: < 80 µA (Touch current) Dimensions (L x W x H): 45.7 mm x 25.4 mm x 21.5 mm Weight: approx. 35 g Safety & EMC Certificates: ANSI/AAMI ES60601-1, IEC/EN 60601-1, 2xMOPP, CE, EAC MTBF: > 9337.3K hrs Manufacturer Warranty: 3 Years Information for MEAN WELL MPM-05-5 The MEAN WELL MPM-05-5 stands out as a high-density, 5W encapsulated type power supply module tailored for the rigorous safety standards of the medical industry. Housed in a miniature 1.8" x 1" package, it is specifically designed for PCB mounting where space is at a premium. Its adherence to 2xMOPP (Means of Patient Protection) and an ultra-low leakage current of less than 80 µA ensures it is fully compatible with BF (patient contact) type medical equipment and portable clinical instruments. Built for long-term reliability, the MPM-05-5 features internal potting that facilitates superior heat dissipation and provides 5G anti-vibration protection, making it ideal for mobile clinical workstations. The unit operates as a Class II isolation device, requiring no functional ground, which simplifies system integration across various medical environments. With a no-load power consumption below 0.075W and a wide operating temperature range of -40 °C to +85 °C, this module delivers exceptional "green" efficiency and robust performance for sensitive healthcare electronics.
