• Output Power: 636 W
• Output Voltage: 12 V DC (Adjustable 10.5 – 13.5 V)
• Output Current: 53 A
• Input Voltage Range: 85 – 264 V AC / 120 – 370 V DC, 47 – 63 Hz
• Efficiency: 88%
• Ripple & Noise: ≤ 100 mVp-p
• Inrush Current: Max. 35 A @ 115 VAC / 80 A @ 230 VAC
• No-Load Power Consumption: < 0.8 W
• Operating Temperature: −40 °C to +70 °C
• Cooling: Built-in cooling fan ON-OFF control
• Protections: Short circuit, overload, over voltage, over temperature
• Isolation Voltage: 4000 V AC (4 kVAC) I/P-O/P (2x MOPP)
• Dimensions (L x W x H): 218 mm x 105 mm x 63.5 mm
• Weight: approx. 1.57 kg
• Safety & EMC Certificates: ANSI/AAMI ES60601-1, IEC/EN60601-1 (Medical MOOP Level), CE, CB, EAC
• Status Indicators & Control: DC OK signal, Remote ON-OFF control, Remote sense, 5V standby
• Warranty: 5 years

Information about the MEAN WELL MSP-600-12

Serving as a high-capacity 12 V power hub for sensitive medical devices and complex automation setups, the MEAN WELL MSP-600-12 delivers up to 636 W of clean output power. Its strict adherence to ANSI/AAMI ES60601-1 and IEC/EN60601-1 medical compliance standards (MOOP level) makes it an ideal fit for modern diagnostic and laboratory equipment. Exceptional build quality is reflected in its high isolation voltage of 4000 V AC alongside an ultra-wide operational thermal range spanning from −40 °C to +70 °C. Equipped with smart fan control, built-in active PFC, and remote sensing capabilities, this unit optimizes overall system stability while keeping idle consumption ultra-low. MEAN WELL highlights this medical-grade power supply's exceptional lifespan with a long-term 5-year warranty.
