• Output Power: 30 W (34.5 W Peak for 10s)
• Output Voltage: 15 V DC
• Output Current: 2 A
• Input Voltage Range: 80 – 264 V AC / 113 – 370 V DC, 47 – 63 Hz
• Efficiency: 90%
• Ripple & Noise: ≤ 120 mVp-p
• Inrush Current: max. 25 A @115 VAC / 45 A @230 VAC
• No-load Power Consumption: < 0.075 W
• Operating Temperature: −40 °C to +85 °C
• Cooling: Free air convection
• Protection Functions: Short circuit, Overload, Over voltage
• Isolation Voltage: 4000 V AC (4KVAC) I/P to O/P
• Medical Safety Class: 2xMOPP level, suitable for BF applications
• Dimensions (L x W x H): 91 mm x 39.5 mm x 28.5 mm
• Weight: approx. 120 g
• Connection Type: Screw Terminal Style
• Vibration Resistance: Up to 5G
• Manufacturer Warranty: 3 Years

Product Information for MEAN WELL MPM-30-15ST

The MEAN WELL MPM-30-15ST is a high-density 30W medical grade AC/DC power module featuring a convenient screw terminal connection for direct chassis mounting. Engineered to meet the highest safety standards, it complies with 2xMOPP (Means of Patient Protection) and exhibits an ultra-low leakage current (< 80µA), making it fully suitable for BF-rated patient contact medical devices. This "ST" variant is specifically built for durability, offering a significantly higher vibration resistance of up to 5G compared to standard PCB-mount versions, which is essential for mobile medical clinical workstations.

This eco-friendly power solution is designed for maximum efficiency, boasting a no-load power consumption of less than 0.075W to support green energy requirements. With a high efficiency of 90% and a 10-second peak load capability of 34.5W, the MPM-30-15ST provides a stable 15V output even during transient power demands. Its Class II double insulation design eliminates the need for a protective earth ground, while the wide operating temperature range from -40 to +85 °C ensures reliable performance in diverse clinical environments, from diagnostic monitors to medical examination instruments.
