• Output Power: 19.8 W (25.7 W Peak for 10s)
• Output Voltage: 3.3 V DC
• Output Current: 6 A
• Input Voltage Range: 80 – 264 V AC / 113 – 370 V DC, 47 – 63 Hz
• Efficiency: 82.5%
• Ripple & Noise: ≤ 80 mVp-p
• Inrush Current: max. 25 A @115 VAC / 45 A @230 VAC
• No-load Power Consumption: < 0.075 W
• Operating Temperature: −40 °C to +85 °C
• Cooling: Free air convection
• Protection Functions: Short circuit, Overload, Over voltage
• Isolation Voltage: 4000 V AC (4KVAC) I/P to O/P
• Medical Safety Class: 2xMOPP level, suitable for BF applications
• Dimensions (L x W x H): 91 mm x 39.5 mm x 28.5 mm
• Weight: approx. 120 g
• Connection Type: Screw Terminal Style
• Vibration Resistance: Up to 5G
• Manufacturer Warranty: 3 Years

Product Information for MEAN WELL MPM-30-3.3ST

The MEAN WELL MPM-30-3.3ST is a 30W high-density AC/DC screw terminal type medical power supply, engineered for quick and secure integration into professional healthcare equipment. This model is fully compliant with 2xMOPP (Means of Patient Protection) standards and features an ultra-low leakage current (< 80µA), ensuring maximum safety for BF-rated patient contact applications. The "ST" version provides convenient mounting options and elevated mechanical durability, specifically rated to withstand vibration demands up to 5G.

As a "Green" power solution, the MPM-30-3.3ST consumes less than 0.075W under no-load conditions, meeting global energy efficiency mandates. It delivers a steady 3.3V DC output and can handle peak loads of up to 25.7W for 10 seconds, which is essential for managing startup surges in clinical instruments. With Class II double insulation and a broad operating temperature range of -40 to +85 °C, this module is an exceptionally reliable choice for portable medical devices, clinical monitors, and mobile medical workstations where grounding may not be available.
