• Output Power: 31.2 W (34.5 W Peak for 10s)
• Output Voltage: 48 V DC
• Output Current: 0.65 A
• Input Voltage Range: 80 – 264 V AC / 113 – 370 V DC, 47 – 63 Hz
• Efficiency: 90%
• Ripple & Noise: ≤ 200 mVp-p
• Inrush Current: max. 25 A @115 VAC / 45 A @230 VAC
• No-load Power Consumption: < 0.075 W
• Operating Temperature: −40 °C to +85 °C
• Cooling: Free air convection
• Protection Functions: Short circuit, Overload, Over voltage
• Isolation Voltage: 4000 V AC (4KVAC) I/P to O/P
• Medical Safety Class: 2xMOPP level, suitable for BF applications
• Dimensions (L x W x H): 91 mm x 39.5 mm x 28.5 mm
• Weight: approx. 120 g
• Connection Type: Screw Terminal Style
• Vibration Resistance: Certified up to 5G
• Manufacturer Warranty: 3 Years

Product Information for MEAN WELL MPM-30-48ST

The MEAN WELL MPM-30-48ST is a high-density 30W medical grade AC/DC module featuring integrated screw terminal blocks for quick and secure chassis mounting. Specifically designed for healthcare environments, it adheres to 2xMOPP (Means of Patient Protection) standards and features an ultra-low leakage current (< 80µA), qualifying it for use in BF-rated patient contact equipment. The "ST" model stands out due to its enhanced mechanical durability, engineered to handle significant vibration levels up to 5G, which is critical for mobile clinical workstations and diagnostic tools.

This eco-friendly power solution is highly efficient, with a no-load power consumption of less than 0.075W, supporting modern green energy requirements in medical facilities. The module provides a stable 48V output and features a robust peak load capacity of 34.5W for 10 seconds, allowing it to easily manage transient power surges during equipment startup. With Class II double insulation and an extensive operating temperature range from -40 to +85 °C, the MPM-30-48ST delivers a versatile, maintenance-free, and highly reliable power source for professional medical monitors and examination instruments.
