• Output Power: 31.2 W (34.5 W Peak for 10s)
• Output Voltage: 48 V DC
• Output Current: 0.65 A
• Input Voltage Range: 80 – 264 V AC / 113 – 370 V DC, 47 – 63 Hz
• Efficiency: 90%
• Ripple & Noise: ≤ 200 mVp-p
• Inrush Current: max. 25 A @115 VAC / 45 A @230 VAC
• No-load Power Consumption: < 0.075 W
• Operating Temperature: −40 °C to +85 °C
• Cooling: Free air convection
• Protection Functions: Short circuit, Overload, Over voltage
• Isolation Voltage: 4000 V AC (4KVAC) I/P to O/P
• Medical Safety Class: 2xMOPP level, suitable for BF applications
• Dimensions (L x W x H): 69.5 mm x 39 mm x 24 mm
• Weight: approx. 102 g
• Safety Certificates: IEC/EN60601-1, ANSI/AAMI ES60601-1, TUV, EAC, CE
• Leakage Current: Ultra-low (< 80µA)
• Manufacturer Warranty: 3 Years

Product Information for MEAN WELL MPM-30-48

The MEAN WELL MPM-30-48 is a professional-grade 30W encapsulated AC/DC module providing a stable 48V output for medical systems that prioritize safety and miniaturization. It is fully compliant with 2xMOPP medical isolation regulations and maintains a leakage current of less than 80µA, making it the perfect choice for BF-rated patient contact equipment. The unit is housed in a robust, fully potted plastic case that ensures high thermal dissipation and protects sensitive electronics against environmental contaminants and vibrations up to 2G.

This eco-friendly "Green Power" solution features an extremely low standby power consumption of < 0.075W, assisting manufacturers in meeting modern energy-saving directives. The MPM-30-48 supports a 10-second peak load capacity of 34.5W, offering critical headroom for specialized medical monitors and diagnostic tools. With Class II double insulation and a broad operating range of -40 to +85 °C, this high-density power supply delivers consistent, high-performance energy for medical clinical workstations and portable examination instruments worldwide.
