• Output Power: 10 W
• Output Voltage: 5 V DC
• Output Current: 2 A
• Input Voltage Range: 80 – 264 V AC / 113 – 370 V DC, 47 – 440 Hz
• Efficiency: 81%
• Ripple & Noise: ≤ 100 mVp-p
• Inrush Current: 25 A @ 115 VAC / 45 A @ 230 VAC
• No-load Power Consumption: < 0.075 W
• Operating Temperature: -30 °C to +85 °C
• Cooling: fanless natural convection
• Protections: Short circuit, Overload, Over voltage, Over temperature
• Isolation Voltage: 4000 V AC between input and output
• Leakage Current: < 80 µA
• Dimensions (L x W x H): 45.7 mm x 25.4 mm x 21.5 mm
• Weight: approx. 35 g
• Safety & EMC Certificates: ANSI/AAMI ES60601-1, IEC/EN60601-1, 2xMOPP, CE, CB, EAC
• Manufacturer Warranty: 3 years

Information about the MEAN WELL MPM-10-5

The MEAN WELL MPM-10-5 is a high-density medical grade AC/DC module designed to deliver reliable power in a compact 1.8" x 1" form factor. As detailed in the MPM-10-spec.pdf, this series is medical safety approved for 2xMOPP applications and features an ultra-low leakage current of less than 80 µA, making it perfectly suitable for BF rated equipment. Its encapsulated design provides excellent protection against environmental factors while maintaining a high lifespan due to superior interior potting.

A key characteristic of this power supply is its green energy efficiency, achieving a no-load power consumption of under 0.075 W. Designed for Class II configurations, it operates without a functional ground and provides a high isolation voltage of 4KVAC. The unit is highly resilient, capable of withstanding 5G anti-vibration forces and operating in temperatures ranging from -30 to +85 °C, which makes it an ideal choice for portable medical devices, clinical workstations, and sensitive examination instruments.
