PM-05-24 End of Life

Technical Information & Details for MEAN WELL MPM-05-24 Power Supply Output Power: 5.52 W Output Voltage: 24 V DC Output Current: 0.23 A Input Voltage Range: 80 – 264 V AC / 113 – 370 V DC, 47 – 440 Hz Efficiency: 82% Ripple & Noise: ≤ 180 mVp-p Inrush Current: max. 25 A @115 VAC / 45 A @230 VAC No-load Power Consumption: < 0.075 W Operating Temperature: −40 °C to +85 °C Cooling: Free air convection Protection Functions: Short circuit, Overload, Over voltage, Over temperature Isolation Voltage: 4000 V AC (Input to Output) Leakage Current: < 80 µA (Touch current) Dimensions (L x W x H): 45.7 mm x 25.4 mm x 21.5 mm Weight: approx. 35 g Safety & EMC Certificates: ANSI/AAMI ES60601-1, IEC/EN 60601-1, 2xMOPP, CE, EAC MTBF: > 9337.3K hrs Manufacturer Warranty: 3 Years Information for MEAN WELL MPM-05-24 The MEAN WELL MPM-05-24 is a high-density, 5W AC/DC encapsulated type power supply module engineered for high reliability in medical applications as detailed in MPM-05-spec.pdf. Housed in a miniature 1.8" x 1" footprint, it is an ideal solution for compact PCB layouts requiring a steady 24V output. Its strict adherence to 2xMOPP (Means of Patient Protection) and an ultra-low leakage current of less than 80 µA ensures safe operation in medical devices with direct patient contact (BF rating). Engineered for long-term stability, the MPM-05-24 utilizes internal potting to facilitate superior heat dissipation and provide 5G anti-vibration durability. This Class II isolation device requires no functional ground, simplifying its integration into mobile clinical workstations or portable diagnostic tools. With a no-load power consumption below 0.075W and a broad operating temperature range of -40 °C to +85 °C, this module delivers exceptional efficiency and robust performance for sensitive healthcare electronics.
