• Output Power: 5025 W
• Output Voltage (DC): 24 V DC (Adjustable Range 19 – 33 V)
• Output Current: 208 A
• Communication: MODBus-RTU (RS-485 interface)
• Input Voltage Range (AC): 180 – 305 V AC, 47 – 63 Hz
• Efficiency: Up to 92.5 %
• Ripple & Noise: ≤ 2.8 Vp-p
• Bidirectional Transfer Time: Typically 1 ms
• Inrush Current: max. 120 A @ 230 V AC
• Operating Temperature: −30 °C to +70 °C
• Cooling: Intelligent fan control
• Protection Functions: Anti-islanding, Short Circuit, Overload, Over Voltage, Over Temperature
• Over Voltage Category: OVC III
• Withstand Voltage: 6000 V DC (Input to Output)
• Dimensions (L x W x H): 460 mm x 211 mm x 83.5 mm
• Weight: Approx. 12 kg
• Safety & EMC Certificates: CE, UL, TUV, CB, EAC, UKCA
• Manufacturer Warranty: 5 Years

Information about the MEAN WELL BIC-5K-24MOD

The MEAN WELL BIC-5K-24MOD is a high-performance 5kW bidirectional power supply designed to facilitate advanced energy recycling in industrial environments. This specific "MOD" version features a built-in MODBus-RTU protocol, ensuring seamless digital integration for real-time monitoring and control of power parameters. Its primary strength is the dual-mode operation, capable of AC-to-DC charging and DC-to-AC grid reinjection with a total harmonic distortion of less than 3%. The unit boasts an ultra-fast 1ms bidirectional transfer time, allowing for nearly instantaneous transitions between energy sourcing and recycling. Engineered for maximum reliability, the device includes conformal coating for environmental protection and complies with Over Voltage Category III standards for direct grid connection. For high-capacity requirements, the BIC-5K-24MOD supports active current sharing, enabling the parallel connection of up to 6 units for a massive total power output of 30kW, making it ideal for battery formation, V2G systems, and energy storage testing.
